Description:

BRANDT AMBITION 1210 (aka KDF 210) EDGEBANDER (W/PRE-MILLING): Specifications:0.4 - 3 mm (1/8") Edge cap., panel thickness from 8 - 40 mm (5/16" - 1-9/16"), min. panel length 120 mm (4-3/4") and 70 mm (2-3/4") min. width. -- Feed Speed:Feed chain track speed 8 MPM (26 FPM) w/gear motor feed drive; Pre-Mill Station: -- 2-Motor Pre-mill (1 HP- 12,000 RPM @ 200 Hz).Gluing Station: -- "A3" Gluing Unit for granulate adhesive application system with Quick Change application unit underneath glue reservoir, Automatic reduction of glue temperature upon interruption of work. -- Automatic magazine for coil (table 800 mm dia. to accommodate large coils of 3 mm material) stock; Heavy Duty guillotine, strips stacking with automatic strip separation on feeding. -- Pressure zone with driven main roller & (2) idle post pressure rollers; Digital readout for manual adjusting pressure zone to edge thickness. Work stations: -- End trim of front & rear edge(0.24 HP - 12,000 RPM @ 200 Hz motor ea. with 100 mm dia. saw blade). -- Top & bottom Flush/Chamfer/Radius trimming(0.36 HP - 12,000 RPM @ 200 Hz motor ea.), sensing horizontally & vertically,DFC combination cutters for flush, chamfer, & radius trimming; (1) set of tools for 3 mm radius, digital readouts for fast adjustment. -- Radius Glue Joint Scraping unitTop & bottom for removal of adhesive residue for perfect finish, sensing from top & bottom; height adjustment with top pressure beam. -- Glue Joint Scraping unitTop & bottom for removal of adhesive residue for perfect finish, sensing from top & bottom; height adjustment with top pressure beam, equipped with (2) reversible cutter knives. -- Operator Interface:"ECO Plus Control", easy operation with simple menu format; large LCD display and integrated line control via keypad. -- Complete With: Top pressure with (2) single rows of staggered rubber rollers Transport chain with 80 mm wide with replaceable rubber pads Workpiece support track extends up to 300 mm (11.8"). Individual dust extraction ports and Sound & safety enclosure.
