Description:

BIESSE ROVER C 6.40 CONF 3 FT - 5' x 12' CNC Machining Center with ATC/Boring (5-AXIS PROCESSING): -- Specifications: Working Capacity: "X" Axis 144" (3,650 mm); "Y" axis 60.2" (1,530 mm); "Z" axis stroke 26.1" (663 mm); max. material thickness 10.8" (275 mm). -- Positioning Speed:"X" & "Y" Axes 328 FPM (100 MPM) each; "Z" axis 98 FPM (30 MPM). -- Worktable:(10) EPS (Electronic Positioning System) Panel supports with: (8) Lifting bars; (4) ATS vacuum pods with universal clamping systems per panel support.(2) Independent working areas with: (10) Pneumatic back stops, (2) pneumatic side stops & (2) pneumatic central stops. -- Boring Unit:4 HP (3 kW) Motor with variable speed from 1,500 - 7,500 RPM; (5) independent vertical spindles in "Y" axis.(4) Horizontal boring spindles with: (1+1) in "X" axis & (1+1) in "Y" axis. -- Machining:(1) 16 HP (12 kW) Liquid Cooled 5-AXIS electro spindle router with HSK F63 adaptor; variable speed from 3,000 - 24,000 RPM.(1) 8-Position ATC tool plate, mounter at the Router's head for "On the Fly" Tool change. -- Operator & Machine Control:PC Front-End with BIESSE "NC 1000" + "BiesseWORKS" + WINDOWS "XP" Operating System. 15" Color CRT, full keyboard, mouse, 1.44 MB & CD ROM disk drives. RS 232 & USB ports. Ethernet connection, specific function controls, & and Internet trouble shooting capabilities. Air-conditioned control cabinet & dust free environment. "BiesseWORKS" is a multitask Operating System with: Input/output modules, axes override, (4) axes interpolation, diagnostic graphics aid for programming, machine data & tool management. -- Complete with:(1) 250 m³/Hr Vacuum Pump; safety fences & mats; original documentation; user & maintenance manuals, wiring diagrams & operation of Numerical Control. -- Options Include:(1) Ingersoll Rand Air Compressor & Air Dryer, and (1) MicroAir Dust Collector, as pictured -- Actual Model is BIESSE ROVER C 6.40 CONF 3 FT
