SCMI SIGMA PRIMA 50 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications: Working cap:149.6" (3,800 mm) Max. rip cut cap. 125.9" (3,200 mm) pusher stroke; 1.96" (50 mm) max. saw blade projection; 12 HP (9 kW) main saw motor (3,900 RPM); 2 HP (1.5 kW) scoring saw motor (6,300 RPM).Main blade diameter: 11.8" (300 mm), Main blade arbor diameter: 80 mm; Scoring blade diameter: 6.37" (160 mm), Scoring blade arbor diameter: 55 mmAutomatic exclusion of scoring unit when motor is in off position. -- Saw carriageFeed speed 0 - 327 FPM (0 - 100 MPM), return speed 327 FPM (100 MPM),Automatic saw carriage lubrication, balanced on hardened cylindrical guides; external score saw adjustment, THK guides for vertical saw movement. -- Pusher Fence:Feed Speed 0 -230 FPM (0 - 70 MPM) forward speed, 230 FPM (70 MPM) reverse speed;Programmable rear fence with (7) material gripper clamps, rack & pinion movement,Grippers fit into a slotted pressure beam for positive material control during the final cut. -- Operator & Machine Control:PC front-end with: SCM Real time "WinCut" + Windows "7 Professional" operating system; Pentium 300 MHz, 6.4 GB hard drive, 64 MB RAM,17" color super VGA flat screen monitor, on-screen diagnostics & production reports; (2) serial ports & (1) parallel port, spacing available for networking cards. "Cutty" optimization software is included which allows: 30 lines per program, 300 max number of pieces per line, and 3 cutting levels. -- Complete with:Side alignment device: Min. part width 2.36"; Max. part width 48"; Rear support rails with rollers;(1) Front fixed air table 98" x 24" (2,500 x 609 mm), (2) Adjustable air tables 59" x 24" (1,500 x 609 mm).Plastic safety guards; emergency stop bar; enclosed cutting area; triple dust collector outlet. -- Actual model is SCMI SIGMA PRIMA 50.

2008 SCM Morbidelli Universal 3612

SCM TECH Z 30 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications:Working Field "X" axis 120" (3,050 mm); "Y" axis 52.7" (1,340 mm) for routing & 44" (1,118 mm) for boring; "Z" axis stroke 7.8" (200 mm); max. material thickness 3.9" (100 mm). -- Positioning Speed:"X" & "Y" Axes are 197 FPM (60 MPM); "Z" axis is 72 FPM (22 MPM).Axes positioning by: AC Brushless motors and YASKAWA drives; high precision ball screw drive system in "X", "Y". "Z" Axes;All axes ride on prismatic guideways & sliding blocks. -- Worktable:(6) "TV" Tubeless mobile support rails, (2) vacuum pods per rail; (4) pneumatic lifter rails for heavy panels.(6) Pneumatic pop-up backstops, (6) pneumatic pop-up front stops; (2) pneumatic pop-up side stops.LED Display positioning assistance for the support rails & vacuum pods; (2) independent working fields. -- Boring Head:3 HP (2.2 kW) motor - 4,000 RPM; (15) independent vertical spindles: (8) Spindles in "X" & (7) spindles in "Y".(6) Horizontal spindles (2 + 2) in "X" & (1 + 1) in "Y-axis".(1) X-axis grooving saw with 100 mm dia. blade - 6,000 RPM. -- Machining:(1) 10 HP (7.5 kW) Electro-spindle router with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM, max. torque achieved at 12,000 RPM.Static inverter for stepless speed & rapid shutdown rotation.(1) 6-Position ATC tool plate mounted on the on the machine for "on the fly" ATC; max. tool weight is 8 kG (17.6 Lbs). -- Operator & Machine Control:PC Front-End with: SCM "UNIVERSAL K2" + "Xilog Plus" + Windows "XP" Pro Operating System; 15" CRT color display, CELERON 2 GHz processor, enclosed in air-conditioned cabinet. -- Complete with:(1) 100 m³/Hr Vacuum Pump; automatic lubrication system; "BUMP STOP" safety system. -- Actual Model is SCM TECH Z30 R6

SCM SANDYA - 40 M3 135, ...3-Head Wide Belt Sander 52" Width cap. Drum, Drum, Combination HeadHead Configuration:1st Head: Steel Contact 22 kW Pneumatic blowdown and alignment.2nd Head : Rubber Contact 18.5 kW Pneumatic blowdown and alignment.3rd Head: Combination Platen 15 kW Pneumatic blowdown and alignment.Note:The SCM sander does not have a brush. After the 3rd head, it has this pneumatic blow-off bar with multiple blow-offs running the length of the sanders width. Sander can be seen under power if needed.Specifications: -- 53" x 103" Abrasive belts with electronic tracking. -- All heads with abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 5 HP motor. -- Automatic part thickness adjustment. -- Motorized thickness opening via (4) precision conveyor bed jacks with LED readout. --0" - 7-7/8" opening. -- Equipped with & Features -- Outfeed rubber covered holddown rolls or shoes on all heads. -- Motor load meters. --Infeed and outfeed conveyor extensions. -- WYE-DELTA soft start.Note: The SANDYA model "40" is more or less the same as the SANDYA "30" but more Heavy Duty.

SCM Sandy 10 -RCS-110 Wide Belt Sander (2) Heads43" Width cap. Drum, Combination HeadHead Configuration:1st. Head: 7" diameter corrugated metal roller for calibration 35 HP ( Drives both Heads )2nd Head: Combination head with 7" dia. contact roller (spiral grooved rubber covered); air/jump finishing platen controlled with timers to eliminate any rounding on leading & trailing edges of the panel, 2" wide platen.Specifications --103" long x 43" wide Abrasive belts --Air tracking, floating & rigid bed for sanding of veneers & solid panels; infeed & outfeed spring loaded holddown rolls -- Minimum workpiece length 16" --Thickness capacity 6.25". --Separate 2.5 H.P. variable speed feed motor delivering feed speeds from 15 to 70 FPMNote: The seller has 20 boxes of various sandpaper belts (80 – 150 grit) that will be included.

SCM SANDYA 15S (3) Head Wide Belt Sander42" Width cap, Drum, Drum, Combination HeadHead Configuration:1st Head: Steel contact roll, 7" dia., 35 HP motor;2nd Head: Rubber-covered contact roll, 24 HP motor3rd head: Combination head, rubber-covered contact roll (45 Shore) and 3" wide finishing platen, 17.4 HP motor.Specifications: -- 43" x 103" Abrasive belts -- Electronic tracking & pneumatic belt tensioning, abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 4 HP motor -- Automatic part thickness adjustment -- Motorized thickness opening via (4) precision conveyor bed jacksEquipped With & Features: -- LED readout, 0" - 6-1/4" opening. -- Infeed & outfeed spring loaded rubber covered hold-down rollers -- Motor load meters -- Infeed and outfeed roller conveyor extensions.

SCM - S520 E, ...Planer Specifications: -- 20" Width cap.; 9 HP main motor; 4-3/4" dia. 4-knife TERSA cutterhead at 4,500 RPM. -- 1/8" - 9-1/4" Powered opening with digital readout for fine adjustment; max. depth of cut 5/16"; 10" min. length of workpiece. -- (4) Feed speeds: 20 - 33 - 43 & 56 FPM; table size 20-3/4" x 39".Equipped with: -- Chip breaker; sectional grooved infeed & solid outfeed rollers; (2) adjustable bed rollers. -- Complete with: Magnetic starter & shaving hood.

SCM - S 52, ...Straight Knife Planer20" Width cap.; knife cutterhead; 9 HP main motor (approx.); 1/8" to 9-1/4" motorized opening with mechanical digital readout; max. depth of cut 5/16"; 10" min. length of workpiece; (4) feed speeds at: 21 - 32 - 42 & 55 FPM; table size: 20-1/2" x 33-1/4". -- Equipped with: Chip breaker; sectional grooved infeed & solid outfeed roller.

SCM TECNOMAX SC/4 WS 8-1/2' Sliding Table SawSpecifications: -- Max. depth of cut with 315 mm (12.40") Dia. blade: 100 mm (3.94") at 90°, 70 mm (2.76") at 45°. -- Main saw: 3.6 kW (4.82 HP) Motor, Blade dia. 315 mm (12.40"), Arbor tilt 0° - 45°, Blade speed 4,000 RPM. -- Scoring saw: Blade dia. 100 mm (3.94").Equipped with: -- 11-1/2"; x 102"; x 35-1/2"; H Aluminum sliding table, 840 mm (33.07") LR Fixed table. -- Manual raise, lower & tilt. -- Mechanical digital tilt indicator.Complete with: -- 39-1/4"; L x 3-1/2"; H Rip fence, with 51" Cutting width cap. & Cam-locking. -- 650 x 1,100 mm (29.59" x 43.32") Squaring frame, with Crosscut fence with 1,800 mm (70.87") Cutting cap., (2) Flip stops & Sliding outrigger support.Actual model is SC/4 WS-N.

SCM MINIMAX - FORMULA S1, ...Sliding Table SawSpecifications: -- 120" Cap. with: Scoring; 9 HP main motor & belt driven scoring blade; -- Manual tilting of the arbor 0° - 45°; Manual raise-and-lower of the main blade; -- 50" crosscut capacity with a movable fence.Features: -- "Easy-Set" scoring adjustment; heavy cast iron trunnion; 12" main saw blade dia. with 1" Arbor, 110 mm scoring blade dia.; -- Max. cutting height 3-1/2" at 90° & 2-3/4" at 45°; 1-speed arbor; 8,000 RPM on scoring blade. -- Complete with: 4" Main dust extraction outlet, miter fence & crosscut fence assembly with (2) flip stops.

SCMI SANDYA S300 RCS 110 DUAL HEAD WIDE BELT SANDER43" Width capacity, (1) contact roll & (1) combination head with contact roll & segmented platen.Head Configuration1st Head : 5-1/2" diameter steel calibrating contact roll2nd Head : 5-1/2" diameter rubber covered contact roll and adjustable segmented finishing platen.Specifications -- 0" to 6.69" thickness capacity via motorized bed adjustment with auto set up device. -- Abrasive Belt dimensions 43" X 75" -- Rubber coated pressing rollers before and after working unit -- 1 HP Inverter variable speed feed unit. -- Feed speeds 10 - 60 FPMEquipped with and Features -- Y-Delta two-stage reduced voltage starter on 18 HP main motor -- 2 Roller Infeed and Outfeed table extensions -- Automatic Electronic Table Positioning Device -- Adjustable sanding drum and pad position for micro precision adjustment -- Electronic digital thickness readout of work table position -- Powered table lifting by means of (4) heavy duty motor and lifting columns double fastened at both top and bottom of the lifting columns to provide exceptional table stability -- Electronic tracking of abrasive belt -- Automatic feed mat tracking -- Pneumatic belt tensioning with center fulcrum to compensate for tapering of abrasive belt

SCM SANDYA 7 RCS Wide Belt Sander2-Head, 42" cap. - Great solid wood finish Sander. -- 1st Head: Grooved steel contact roll, 6-1/4" dia., 30 HP motor -- 2nd Head: Combination head, rubber covered contact roll, 6-1/4" dia. (65 Shore), and 2" wide finishing platen, 25 HP motor. -- 43" x 75" or 85" Abrasive belts with electronic tracking & pneumatic belt tensioning, pneumatic exclusion of all contact rolls. -- Conveyor belt feed with variable feed speed, 14.5 - 30 FPM, 1.5 HP motor, automatic part thickness adjustment, -- Motorized thickness opening with LED readout,0" - 6-1/4" via (4) precision conveyor bed jacks. -- Infeed & outfeed spring loaded rubber covered holddown rolls on all heads, -- Motor load meters, infeed and outfeed conveyor extensions, WYE-DELTA soft start.

SCM TECNOMAX - SC/4 WS, ...8-1/2' Sliding Table SawSpecifications: -- Max. depth of cut with 315 mm (12.40"); dia. blade: 100 mm (3.94") at 90°; 70 mm (2.76") at 45°. -- Main saw: 3.6 kW (4.82 HP) Motor; blade dia. 315 mm (12.40"); arbor tilt 0° - 45°; blade speed 4,000 RPM. -- Scoring saw: Blade dia. 100 mm (3.94").Equipped with: -- 11-1/2"; x 102"; x 35-1/2"; H Aluminum sliding table; 840 mm (33.07") LR fixed table. -- Manual raise, lower & tilt. -- Mechanical digital tilt indicator.Complete with: -- 39-1/4"; L x 3-1/2"; H Rip fence with: 51" Cutting width cap. & cam locking. -- 650 x 1,100 mm (29.59" x 43.32") Squaring frame with: Crosscut fence; 1,800 mm (70.87") cutting cap.; (2) flip stops & siding outrigger support.NOTE: Saw is deinstalled as pictured in Photo #2. - Photo #1 shows Seller's other Saw, which is also available to purchase (EXF # PS-011935). Both Saws are one serial number apart. Seller confirms that all machine components are present.

SCM SI 350 N - 10-1/2', ...Sliding Table SawSpecifications: -- Cutting length 3,200 mm (126"); max. depth of cut: 118 mm (4.65") at 90°; 81 mm (3.19") at 45°. -- Main saw: 6.6 kW (9 HP) Motor; blade dia. 250 - 350 mm (9.84" - 13.78"); arbor dia. 1"; arbor tilt 0° - 45°; blade speed 4,000 RPM. -- Scoring saw: 0.75 kW (1 HP) Motor; max. blade dia. 120 mm (4.72"); arbor dia. 20 mm (3/4"); blade speed 8,500 RPM; external scoring blade adjustments.Equipped with: -- 14-1/4"; x 126"; x 35-1/2"; H Aluminum sliding table; 630 mm (24.80") x 1,040 mm (40.94") Fixed table. -- 2-Position table lock mechanism; manual raise, lower & tilt. -- Mechanical digital tilt indicator. -- Pivoting blade guard with dust outlet.Complete with: -- 47-1/4"; L x 3-1/2"; H Rip Fence with: 67" Cutting width cap. -- Crosscut Fence with: 84" Cutting cap.; (2) flip stops & Sliding outrigger support.

SCM M3 Multi-Blade Dip Chain Gang Rip SawSpecifications: -- 300 mm (11.81") Width cap. -- 110 mm (4.33") Max. depth of cut. -- 8-3/4" Throat depth. -- 390 mm (15.35") Min. stock length. -- 200 - 350 mm (7.87" - 13.78") Blade diameter. -- Arbor dia. 70 mm (2.76"). -- Table size 750 x 1,530 x 750 mm H (29-1/2" x 60.24" x 29-1/2" H). -- Blade speed 4,200 RPM. -- Feed speeds 6 - 48 MPM (19 - 157 FPM).Equipped with: -- 44 kW (60 HP) - 3,554 RPM Blade motor. -- Variable speed drive feed chain motor. (2) Upper infeed & (2) Upper outfeed 4" Dia. rollers, Automatic chain lubrication. -- Top & bottom anti-kickback fingers. -- Main dust hood, with 200 mm (7.87") Dia. outlet. -- 40"; x 2-3/4"; H Adjustable infeed fence. -- Motor load meter.Note: Some spec's need to be verified

SCM T 110 I Tilting Spindle Shaper -- Specifications: 6.6 HP Motor, 1-1/4" interchangeable spindle tilts -5° to +45°, (5) spindle speeds of 3,000 - 4,500 - 6,000 - 8,000 & 10,000 RPM. 39" x 29-1/2" Table, 13.4" max. insert opening, digital readout for spindle height setting, 6-1/8" working height under nut; adjustable fence guard assembly. -- Complete with: Mechanical spindle brake, hand spindle lock, reverse rotation switch, (5) table insert rings, and (2) 3" dust outlets. -- Includes: 3-Roll Magi Steff 2034 Power Feeder

SCM Minimax T-50 Tilting Spindle Shaper -- Specifications: -- 1-1/4" Dia. interchangeable spindle tilts -5° to +45°, -- 6.6 HP motor; 3-1/2" cap. under nut, (4) spindle speeds of 1,700 - 4,000 - 7,000 & 9,000 RPM. -- Table size 18" x 43" with adjustable side extension tables; 3" - 5" - 7" & 8" table insert openings -- 4-1/2" max. spindle height above table -- 2" max. tooling retraction under table with 7" max. tooling dia.; working height 37".Equipped with: Outrigger Sliding Table, micro-adjustable fence, spindle lock, magnetic starter w/overload protection, reversing switch, and 4-3/4" dia. dust outlet. Includes: Several New Cutter-heads

SCM - FORMULA S35: Sliding Table SawSpecifications -- 10' Cap. with: Scoring; 9 HP motor for main & scoring blade; tilting arbor: 0° - 45°. -- 126" Table stroke; 51" rip cut capacity with movable fence. -- 350 mm (13-3/4") Main saw blade dia.; 120 mm (4-3/4") scoring blade dia.; max. cutting height: Approx. 120 mm at 90°; 4,000 RPM. Complete with: -- Overhead guard with: 4" Dust extraction outlet. -- Crosscut fence assembly with: (2) Flip stops.

Worktable dimensions: 145? x 61? Z -Axis stroke: 9.84? Spindle speed: 24,000 RPM Electrospindle (S1/S6 rating): 7.5 HP / 9HP Tool Changer: 10 position Spindle Taper: HSK 63 Boring Block (7) Spindles: 6,000 RPM Maximum positioning vectorial speeds: X/Y axis: 115 feet/minute Electrics: 208/230/460 volts, 3-phase, 60 cycles EQUIPPED WITH: Windows Based Operating system 17” Flat Panel Monitor Remote Pendant with 7? Display 7-Spindle Boring Block Touch Probe Spindle Air Blowers Built In Vacuum Pumps- 2 Zones

SCM OLIMPIC K 560 T-ER2 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- SpecificationsEdge Capacity: 0.4 to 6 mm (0.016 to 1/4") For strip feeding. -- Panel Capacity: Min. panel width: 60 mm (2.375"); min. panel length: 140 mm (5-1/2").Min./max. panel thickness: 8 - 54 mm (0.375" - 2.125"); min. distance between panels: 600 mm (24").Equipped with: -- Pre-milling Station: (2) 2.0 HP (1.5 kW) motors; rectifies/cleans panels already sized. -- Adjustable Infeed Fence: Manually preset with digital indicator; pneumatic in/out positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: "SGP" for EVA (Hot Melt) with quick change/disconnect Teflon glue pot for fast glue tanks change if needed; heat up time approx. (10) Min. -- Pressure Section: Manual digital positioning; Teflon coated pneumatic driven roller, and (2) spring loaded idle rollers.Workstations -- End Trimming Station: (2) Front & rear 0.5 HP - 12,000 RPM motors, mounted on THK guides; swivels 0° - 15° for straight & angle cutting. -- Top & Bottom Trimming Unit: (2) 0.7 HP - 12.000 RPM Motors; capable of tilting & pneumatic positioning for (3) settings: Flush/bevel/radius trimming for quick setup. -- Corner Rounding Unit "Round 2M" with: (2) 0.8 HP Independent motors that slide on THK guides. -- Top & Bottom Profile Scraping Unit with: Digital indicators; large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue scraping Unit "RC-N": Eliminates any excess glue. -- Buffing Unit "SP-V": (2) Top/bottom 0.25 HP - 2,800 RPM motors; tilting up to 12°.Operator Interface -- "STARTOUCH" Controller with: 12" Touchscreen display; capable of storing (100) programs. -- Machine automation by PLC function and encoder positioned in the panel feed track pinion. -- Diagnostics for a quick solution to errors: Process statistics data (i.e., number of pieces/edges) and track feeding.Features & Complete with: -- 2-Speed feed speed of 40 & 60 FPM (12 & 18 MPM); (1) 2.5 HP feed drive motor. -- 200 Hz Frequency inverter for all trimming units. -- Electronic Positioning of the top hold-down pressure beam. -- Nesting Copying Device. -- Full sound enclosure cover and outboard panel support. -- Actual Model is: SCM OLIMPIC K 560 T-ER2
