ORMA NPC DIGIT 36/16, ...5' x 12' Electric Hot Press For Solid Surface & Panel Dye SublimationSide Opening Press designed to work with Dye Sublimation materials to print into Solid Surfaces, as well as Panels that can receive Dye Sub Inks. The Press has (6) Pressing Cylinders, 70 mm dia. (2-3/4"), and an opening of 400 mm (15-3/4").Electric Heated Platens: -- ELKOM Germany 3,700 x 1,600 x 24 mm ( 145-1/2" x 63" x 1") + 19 mm (3/4") Monolux + 19 mm (3/4") V100. -- Each platen requires 31 kW, Voltage 440 V / 3 Ph. / 50/60 Hz. -- Max. working temperature is 180°C (356° F). -- Gold anodized surface; massive, solid top of 12 mm (1/2") thick sheet, flat platen surface without any screw; Heat-up time from room temperature to 160°C (320° F): ca. (45) Minutes.Operator & Machine Controls: -- Integrated CNC operator panel on the front right beam with 6"; KTP600 BASIC SIEMENS color Touch-Screen control. -- Complete with individual programmable electronic control (PLC), central unit CPU, and expansion possibility of inputs & outputs. Hardware by SIEMENS, software by ORMAMACCHINE.Manual controls for : -- Push buttons for Press closing and manual Press opening. -- Emergency lamp and emergency push button. -- General on/off switch. -- Power signal lamp.Digital controls for : -- Automatic adjustment of the requested pressure in bar (with automatic recovery of pressuredecrease) obtained by setting the working pieces area and the desired specific pressure. -- Setting & digital display of working temperature on platens. -- Setting & digital display of pressing time for automatic opening. -- Heating platens on/off. -- Automatic switching on of the platens with the possibility to set every day of the week. -- Possibility to store a max. of (20) working programs (temperature, specific pressure, pressing time, and panel dimensions).Special Features: SILICONE MEMBRANE fitted to the upper platen and fixed all around the Press upper structure by means of fast clamping/unclamping units, helps to balance possible uneven profiles and to protect the Press platens from ink transmission.

ORTON - TYPE F, ...Ship Shaper/RouterORTON Type "F" Ship Shaper/Router with: 40" x 60" Table Size. -- 5 HP - 230 Volt, 3-Phase. -- Oil Mist Lubrication. -- Machine "Completely Restored". -- Can be used as a Shaper or Router. -- Comes with: Mandrel with Top Bearing Attachment so the machine can be used as a Tilting Spindle Shaper. -- Also used as a Tilting Spindle Router with: Collet Chuck attachment with: 1" HSS spiral cutter and template guide. -- Heavy-Duty spindle with: BROWN & SHARPE "#11 Tapered Socket" in Spindle. -- Spindle tilts: 30° forward and 45° backward. -- Includes: BROOKS Frequency changer to increase 60-Cycles to 250-Cycles to increase speed of routers to 4,700 RPM. -- Great for cutting changing bevels. -- Approx. weight 3,000 Lbs. -- Lamp & cord NOT included. 5 HP - 230 Volts, 3-phase; in "Excellent Condition." Routers come with: 4 Ft x 14 ft table for clamping down work with patterns; also includes stands. Countertops. Great for cutting multiple pieces without tying up your CNC Router. Routers have been used in 1-Man Shop.

Complete OSAMA Feed Through White Glue Laminating Line, with MIDWEST AUTOMATION Laminate Indexing/Lay-up Table & HMT Laminator Specifications: Line was designed to use the HMT Laminator as a pinch roller with heaters for large quantity runs. The HMT Laminator was used as a stand-alone machine for small quantity runs. Max. panel size 60" x 120" (Based on current outfeed scissor lift platform size. With a 60" x 144" or larger scissor lift, 144" L panels could be run.) Consisting of the following machines as late as 2016: AREDON 48" x 96" Electric/Hydraulic Scissor Lift Platform. 2007 OSAMA SP/RSI-1600 1600 mm (63") Top & Bottom Brush Panel Cleaner, S/N 8103, Min. panel length 430 mm (16.93"), Panel thickness 0 - 100 mm (3.94"), Feed speed 22 MPM (72 FPM), with 290 mm (11.42") Dia. Top & bottom brush rolls with 0.6 mm (0.02") Dia. Black nylon bristles, Spare pair of brushes, 460 V, 60 Cy, 3 Ph., Dimensions 108" X 36" X 70" H, Weight 1,100 Lbs. 2006 OSAMA S2R-1600 1600 mm (63") Top & Bottom Glue Spreader, S/N 20944, Panel thickness 0 - 100 mm (3.94"), Pass line height 800 mm (31.50"), Feed speed 18 MPM (59 FPM), with 185 mm (7.28") Dia. x 64" L Grooved anti-acid rubber-covered top & bottom applicator rolls, each with Manual brush washer, Side glue wipers, Removeable bottom pan, Front & rear safety fences, 230 V, 60 Cy, 3 Ph., Dimensions 90" x 30" x 60" H, Weight 1,500 Lbs. MIDWEST AUTOMATION LT 500 60” x 144” Laminate Indexing/Lay-up Table. 2016 HMT ADVANTAGE PLUS 61" Laminator, S/N 5A391, with 10.5 kW Heatbank, 208 V, 60 Cy, 1 Ph., Dimensions 120" x 83" x 55" H, Weight 1,400 Lbs., NOTE: This machine is also being offered for sale separately (EXF #LA-011186). SOUTHWORTH 5,000 Lb. Capacity 60” x 120” Electric/Hydraulic Scissor Lift Platform, with Gravity roller conveyor top. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

OSAMA SP/RSI-1600 1600 mm (63") Top & Bottom Brush Panel CleanerSpecifications: -- Min. panel length 430 mm (16.93"), Panel thickness 0 - 100 mm (3.94"). -- Feed speed 22 MPM (72 FPM).Equipped with: -- 290 mm (11.42") Dia. Top & bottom brush rolls, with 0.6 mm (0.02") Dia. Black nylon bristles.Available at additional cost: -- Spare pair of brushes.NOTE: This machine is also being offered for sale as a part of a Feed Through White Glue Laminating Line (EXF #LA-011187).

OSAMA S2R-1600 1600 mm (63") Top & Bottom Glue SpreaderSpecifications: -- Panel thickness 0 - 100 mm (3.94"). -- Pass line height 800 mm (31.50"). -- Feed speed 18 MPM (59 FPM).Equipped with: -- 185 mm (7.28") Dia. x 64" L Grooved anti-acid rubber-covered top & bottom applicator rolls, each with Manual brush washer, Side glue wipers. -- 21-3/4"; x 72"; x 2-3/4"; D Removable stainless steel bottom pan. -- Front & rear safety fences.NOTE: This machine is also being offered for sale as a part of a Feed Through White Glue Laminating Line (EXF #LA-011187).

OSI SM-450 Side Matcher LineSide Matcher:FEATURES -- Directly opposing heads (Side-Matcher): Enhances width tolerance and eliminates pistol grip -- Guarantee machining accuracy of +/- 0.002"; (0.05 mm) on width and on tongue/groove position -- Through feed system in both machines: work boards as short as 9"; (229 mm) out of the defecting station; can be processed directly into the Side-Matcher -- Process twisted, crooked and bowed boards -- Hydro-lock collars on all axis -- Feed wheels on independent suspension -- Very low friction -- High precision spindle -- Very short setup time Easy and quick width adjustment -- Easy opening for tool replacement -- Hydraulic unjammingSpecifications: -- Pre-Milling top and bottom with (2) 15 HP motor -- Feed speed 200 to 450 FPM -- Board width 1 1/2" to 8" -- Board thickness: 1/2" to 1 1/2" -- Board length: minimum of 9" trough feed -- Tooling: (2) X 8", RPM 6,000 -- Spindle drive: (2) X 30 HP -- Feed wheels: (2) rows of (4) wheels on top driven by (2) 3 HP motors -- Feed rolls: (3) chromed rolls on bottom driven by (3) 2 HP motor -- Axis movement: on linear bearings

OverBuilt - Baler/LoggerOverBuilt Baler/Loggers are: The fastest, most efficient Baler/Loggers any scrap recycler can own.Compressing scrap metal & vehicles into denser, stackable forms results in more efficient loading &transport. Approx (5,500) hours.Specifications -- Charge box open: 20’ x 8’-5";. -- Closed: 240"; L x 40"; W x 26"; H. -- Bale Size: 40"; x 26"; x Variable. -- Min. variable distance: 22";. -- Bale density: 25 - 80 Lbs/ft³. -- Main compression cylinders: 2. -- Logging force (per side): 175 Tons. -- Charge box door cylinders: 6. -- Baling force (per door): 255 Tons.

PANHANS - 436, ...24'' Single Surface Planer -- Specifications24.8" (630 mm) Width x 1/8" to 10" opening; 10 HP Motor; 4-knife - 4-3/4" dia. cutterhead belt driven @ 5,000 RPM; max. cutting depth: 5/16". -- 1 HP Feed motor with: (2) Feed speeds: 22 - 44 FPM. Segmented rubber-covered infeed and outfeed rollers, sectional chip breaker, motorized raise-and-lower of bed w/LED readout, table size 43" x 21". -- Options Include: (16) Cutter knives: Power lift up & down. -- Complete with: Emergency stop;, magnetic starter w/overload protection; knife setting gauge: & 5-1/2" dia. dust hood; includes: Operations manual; parts list; tool kit.

PAUL K34V/1000 RIP SYSTEM WITH (1) SHIFTING BLADE39.3" (1000 mm) max. cutting width x 4.1" (105 mm) max. thickness cap. -- Specifications: Bottom arbor design; (6) powered bottom and (6) powered top feed rolls propel lumber from the infeed system thru the Ripsaw.50 HP (37 kW) Main motor, 2,900 RPM driving a 2.362" (60 mm) dia. arbor with (1) moveable blade. Moveable saw has a shift-able range of 400mm.Moveable blade and fixed fence positions indicated by 15mw laser lights that project 16' lines down inbound boards. Arbor is removable on a slide system; -- Feed Works: 49 - 262 FPM (15 - 80 MPM) Variable feed speed feed drive; hydraulic drive to (3) sets of smooth top and corrugated bottom feed rolls before and (3) sets of smooth top and corrugated bottom feed rolls after the blades and individually controlled pressure to the feed rollers. With (3) sets of anti-kickback fingers. -- Equipped with: Automatic oiler, push-button station, upper dust hood and upper and lower dust chutes. In-feed roller table 980 mm with (7) rollers; universal type mounted to the machine. -- Operator Interface: 1 NCD control, VGA color monitor, features 10-width lists with 200 items (8 variable-width lists, 2 set-up lists for long bush fitted for fixed blades.) -- Machine is under power but not in production.

PAULSON 4 Head Through Feed MoulderSpecifications -- 4-heads (T-L-R-B) 6" x 2" moulder; -- 7-1/2 HP motor on the 1st top spindle, -- 7.5 HP motor on the left and right -- 7.5 HP motor on the bottom spindle.Equipped with & Features -- 3 HP variable speed feed works with feed speeds from 10 to 75 FPM. -- (2) top and (1) bottom powered feed rolls before the 1st top head --. All spindles are belted from the motors driving at 8,000 RPM are 1-1/4" dia. -- complete with 1/3 of the misc cutterheads shown in the photo. -- NOTE: (3) identical Moulders available. .

PEERLESS MONO 21 UNIT MATERIAL CHIP BINChip Bin main components: -- Bin with 21 Unit (4,200 cubic feet) capacity. -- Hydraulic power unit. -- Steel support structure. -- Clamshell-type material discharge doors. -- Price shown includes dismantling & loading onto trucks.

PHI IR-3 Preheater;Overall dimensions 5' wide x 4' long, consisting of: (3) IR Medium Wave heating banks, each 1" wide x 54" long, bank has gold foil quartz heating elements.This IR unit is designed to preheat the board to facilitate out gassing and help eliminate solvent pop and air bubbles in the coatings of deep pored materials such as oak. Also used to standardize board temps during colder months as well as decrease dry times of other substrates. These units are primarily (but not exclusively) designed for use before the application of stain and sealer coats. Features: Explosion proof electrics, electrical heat temperature adjustable from 100° - 150° F, variable feed speed from 8 - 30 FPM (2.5 - 9 MPM).

PILLAR MACHINE HPLD 96" CNC BORE & LOCK-DOWEL INSERTER: -- Specifications:(4) Working zones of 24" each and "OPTIONAL" working table length of 96"; CNC controlled head assembly with rapid (side-to-side) traverse.Head assembly with: (1) Horizontal boring & insertion unit with a 3 HP - 18,000 RPM Direct-Drive Spindle motor; "X" Axis is servo controlled for positioning; Digital Mechanical Readouts For Height and DepthHead is currently set up to bore/machine/insert 20 mm Lock-Dowel "Eclips", H-clips, Channel Locks & 8 mm Spring Pin Fasteners.Material thickness capacity 0.5" - 1" max. Material thickness with digital readout for height adjustment. -- Clamping System:(8) Pneumatic, quick side-to-side adjustable hold-down clamps for horizontal "Lock-Dowel" processing on the panel edge.(1) Pneumatic Clamping Bar for vertical boring into the panel face/back. -- Operator Interface:15" Color Touchscreen control + Windows 10 Operating System. Ethernet 1 x PCIE Broadcom GbE (or similar), USB: 2 x USB 2.0 (or similar), Serial Port: 1 x RS-232 (or similar)The on-screen graphics of the operator interface have been designed to allow for quick programming at the machine. Typically, programs can be written and recalled in less than one minute.The Interface is open architecture allowing it to integrate with design software that can give hole locations in the form of a .xml file or a bar code (with bar code reader purchase found in options).Standard Features in the software include: 1. Graphic interface to show where holes are to be drilled and if a dowel is to be inserted. 2. Pattern Drilling/Inserting.3. Password protection of certain features/functions. 4. Online diagnostic capability (if machine is connected to an internet connection). 5. Toggle between Metric or Imperial programing parameters. -- Features: This machine will insert H-clips, Channel Locks and Spring Pins with ease. Using CNC control, this machine positions the drilling spindle to bore holes and insert the Lockdowel hardware. -- Complete with:Anti slip table surface, rack & pinion drive, and centralized dust collection manifold. -- Actual model is: PILLAR MACHINE HPLD

PINHEIRO - MF 4-630: 4-Sided PlanerSpecifications -- 24" Planing width and 20" molding width cap.; 8" max. motorized opening via 0.5 HP motor. -- Top Head: 18 HP; 5" x 25", 4 knives; 5,500 RPM; cutting circle: 50-1/4"; max chip removal: 3/8". -- Bottom Head: 12 HP Motor; 5" x 25"; (4) knives; 5,500 RPM; cutting circle: 5-1/4"; max. chip removal: 3/8". -- (2) Side heads (opposed) with: 8" Spindle capacity; 9 HP each motor; vertical adjustment: 4". -- 11/16" Max. profile depth; 5-1/2" max. tool dia.; 1-13/16" spindle dia. x 8" long at 5,000 RPM. -- 4 HP Feed drive; variable feed speed: 10 - 100 FPM; 39" infeed bed; (6) powered feed rolls; sectional feed rolls; sectional chipbreaker; central lubrication system.Complete with: -- High-speed steel knives in the top & bottom heads; dust hoods.

PIQUA - PW72-50, Semi-Automatic Wide-Mouth Horizontal Baler with MAX-PAK ConveyorSpecifications: -- Cylinder: 7" -- Main motor: 30 HP -- Bale size: 48″ x 36″ x 72″ -- Feed opening: 46" x 50" -- Cycle time: 20 Seconds -- Platen force: 86,600 Lbs -- Bale weight: 1,500 – 1,800 Lbs -- Door cylinder: 4" -- Door cylinder stoke: 12"; -- Conveyor belt: 60"Equipped with: -- 60" Infeed Conveyor with rubber belt.NOTE: New Conveyor rubber belt, paint, and safety stickers.

PMK C 1203 Single End Coping/Tenoning Machine -- With the C-1203 Coping Machine you can run stiles first or cope first, this machine using a 5 HP motor has counter rotating spindles to insure chip free coping of either square, single profiled or double profiled parts. -- Since we are only coping one end at a time the length doesn't matter. We can also cope more than one part at a time up to 9.5" wide on the C-1203. -- (2) Counter rotating spindles 1.25" diameter. -- Spindle Speed 7,000 RPM; cycle time approx. (4) seconds. -- Side Pressure Clamp to insure proper alignment with fence. -- Cutter Heads totally enclosed for Safety!

PMK C 1205 Single End Coping Machine -- With the C-1205 Coping Machine you can run your Styles first or run your cope first, this machine using a 7.5 HP motor has counter rotating spindles to insure Chip free coping of either square. -- Single profiled or double profiled parts. Since we are only coping one end at a time the length doesn't matter. We can also cope more than one part at a time up to 13.5" wide on the C-1205. -- Two counter-rotating spindles 1.25" in Diameter. -- Capacity of maximum (2) cutters on stack tooling -- Spindle Speed 7,000 RPM; cycle time approx. (4) Seconds. -- Side Pressure Clamp to insure proper alignment with a fence. -- Cutter Heads totally enclosed for Safety!

PNEUMAFIL 13.5-460-8 Reverse Air Dust Collector System;Reverse Air Dust Collector with 42,600CFM at 9 to 1 air cloth ratio, 4,738 square feet of filter area. -- 13-1/2' Dia. round baghouse contains (460) bags - 96" long by 5" dia. filter bags in galvanized cages w/reverse jet bag cleaning. -- Reverse Air from 15 HP blower motor which cycles once a minute over filter bags (rotating plenum covers each row of bags once a minute, reversing the normal air flow direction. -- Reverse Air action back flushes the bags and dislodges wood dust particles collected on the filter media which then fall to the bottom of the 60° funnel hopper for removal), bags are changed via walk-in door.. -- Material handling fan with approx. 48" inlet dia with 150 HP floor mounted motor (covered in a shed); 0.25 HP explosion proof motor for manifold drive. -- Rotary Air Lock, gearmotor driven at the bottom of the hopper feeding and shared horizontal screw type auger (if you want it) with gearmotor drive. -- Features: MOTOTRONICS Soft Start for main motor. FIRETEK Spark Detection System (subject to prior sale with adjacent unit). -- Includes: Explosion doors, sprinkler pipe, interior electrical control panel, support frame, safety ladder, railings, and exterior ductwork.Professional dismantling, rigging, transport and installation is available.NOTE: Unit being sold under this record is pictured on the left side on the first two photos. For the smaller diameter unit on the right side (DIXIE AIR) see record "DO-011266".

POWERMATIC Shaper TS-29, with Sliding Table & Tilting SpindleSpecifications: -- 3/4", 1", & 1-1/4" Dia. interchangeable tilting spindle, 3/8" & 1/2" collet & router bit adapters, tilts 45° forward and 5° back, 7-1/2 HP - 3,600 RPM motor; 3,000 - 4,000 - 6,000 - 8,000 - 10,000 RPM spindle speeds via 4-step V-pulley with "quick release". -- 4-3/4" Cap. under nut when using the 1-1/4" spindle, 7-1/16" spindle travel; 51-1/2" x 33-1/2" extra thick cast iron main table, (3) removable table inserts 2-1/2" - 5-1/2" & 5-7/8" x 4-3/16" (oval).Complete with: -- Large scale "ACCU Fence" with integrated 4" dust collection shroud, reversing switch, AMBI-TECH electronic brake, cutterhead guard, clamping miter gauge & magnetic control; incl. owners manual & parts list. Actual Model # 1791284

POWERMATIC - TS-80, ...Single Spindle ShaperAccepts: 3/4" - 1" - 1-1/4" Dia. interchangeable spindles; 5-1/2 HP motor; 3,625 - 5,000 - 7,250 - 10,000 Spindle speeds. -- 4" Cap. under nut when using 1-1/4" spindle; 6-19/64" spindle stroke; approx.: 39-1/2" x 31-1/2" Extra thick cast iron main table. -- Complete with: Adjustable split fence; spring hold-downs; removable table inserts; dust collection shroud; reversing switch; spindle brake; cutter-head guard. -- Includes: Infeed & outfeed tables shown in picture and a box of spindles. - NOTE: Needs some work on bearings.
