LHI POWER RIPPER Straight Line "Rip Saw":Will perform 80% of the jobs done by other Straight-line Rips costing up to four times as much.Specifications: -- 10 HP arbor motor - 230V 1-Phase or 220/440V 3-Phase -- 1 HP feed motor and integral feed unit. -- Variable speed drive or 50 to 180 FPM; fixed feed speeds available (150 FPM standard). -- Cogged steel drive wheels, optional non-marking Polyurethane wheels. -- Easy to change 12" dia. blade - just drop the arbor frame, loosen the arbor nut and change blade. -- Fully enclosed blade plus heavy-duty kickback fingers and heavy gauge belt and chain guards. -- Easy-adjust fence with hand crank and positive lock clamps. -- 4' x 5' Table size with right or left-hand fence available.Options & Features: -- Can be set up to rip hardwoods or softwoods up to 2.75" thick and 3/4" plywood or particleboard up to 4' x 8' in size. -- Available with Quick-Set Fence and digital readouts for lightning-fast size changes.Digital readout, add $2,495

LIGNA 8X40 Multi-Blade Edger/Gang Saw. 40" Wide by 8" high opening. Specifications: -- Bottom saw edger with (5) blades. Powered by a 125 HP TEFC motor. -- Features stacked air cylinder setworks with independent shifting on (3) blades. -- Infeed table with pop-up chains and fence, outfeed rollcase. -- Includes: Powered infeed and outfeed steel roll conveyors.

Dust Collection Pipe (Snap Ring type Pipe)Quantity - Diameter - Length Description(2) 22" - 12" - 38" Branch.(1) 24" - 12" - 38" Branch.Many loose Snap Rings in the tote.(1) 25" - 59" Pipe.(4) 22" - 59" Pipe.(2) 24" - 59" Pipe.(1) 24" x 22" x 6" 21"; Reducer with branch.(1) 22" x 20" x 12" 33"; Reducer with branch.(1) 11" x 10" x 10" 29"; Reducer with branch.(1) 12" Auto gate.(18) 10" - 59" Pipe.(2) 9" - 59" Pipe.(1) 11" - 59" Pipe.(4) 12" - 59" Pipe.(1) 22" - 29" Pipe.(1) 20" - 50" Elbow.(1) 20" x 16" x 12" - 33" Reducer with branch.(1) 24" x 24" x 10" - 29" Branch.(1) 24" x 24" x 6" - 24" Branch.(1) 16" x 12" x 7" x 7" - 45" Reducer with branch.(1) 22" x 22" x 6" - 20" Branch.(7) 12" - 59" Pipe.(4) 14" - 59" Pipe.(1) 16" - 43" Pipe adj.(18) 8" - 59" Pipe.(68) 6" - 59" Pipe.(10) 3" - 59" Pipe.(2) 8" - 32" Pipe.(32) 8", 9", 10", 11" - 59" Pipe.(46) 5" - 59" Pipe.(8) 7" - 59" Pipe.(39) 4" - 59" Pipe.(1) 14" x 12" x 6" - 21" Reducer & branch.(1) 14" x 14" x 6" - 21" Branch.(20) 3", 4", 5", 6" - Various pipe. (1) 6" x 6" x 6" - 21" Branch.(1) 10" x 10" x 4" - 17" Reducer.(1) 10" x 7" x 7" - 23" Reducer.(1) 10" x 9" x 4" - 17" Reducer & branch.(1) 10" x 7" x 7" - 23" Reducer & branch.(1) 10" x 7" 9" Reducer(5) 10" - 18" 90° Elbows.(20) 5" - 8" 90° Elbows.(7) 7" - 8" 90° Elbows.(23) 6" - 8" 90° Elbows.(20) 8" - 20" 90° Elbows(4) 5" - 6" Saddle.(1) 7" x 4" x 4" - 19" Reducer & branch.(2) 8" x 7" x 6" - 21" Reducer & branch.(1) 7" x 6" x 4" - 17" Reducer & branch.(1) 11" x 11" x 9" - 31" Branch.(1) 12" x 8" x 8" - 19" Reducer & branch.(1) 7" x 6" x 5" - 19" Reducer & branch.(1) 11" x 10" x 4" - 17" Reducer & branch.(1) 14" - 39" - 90° Elbows.(1) 9" - 20" 90° Elbows.(2) 10" - 16" 90° Elbows.(1) 7" 22" Pipe.(1) 10" x 10" x 4" - 17" Branch.(2) 10" x 8" x 6" - 21" Reducer & branch.(1) 14" - 39" 90° Elbow.(1) 9" - 20" 90° Elbow.(2) 10" - 16" 90° Elbows.(1) 7" - 22" Pipe.(1) 10" x 10" x 4" - 17" Branch.(2) 10" x 8" x 6" - 21" Reducer & branch.(1) 8" x 8" x 6" - 23" Branch.(1) 12" x 10" x 6' - 21" Reducer & branch.(1) 8" x 6" x 4" - 18" Reducer & branch.(28) 4", 5", 6", 7", 8", 9", 10", 14" Misc.(1) 14" x 11" x 6", 6" 42" Reducer & branches.(1) 8" x 7" x 6" - 21" Reducer & branch.(1) 12" x 7" x 7" - 34" Reducer & branch.(1) 12" x 11" x 4" - 17" Reducer & branch.(1) 5" x 5" x 5" - 17" Branch.(1) Batch 50' - 24" Straight pipe.(1) Batch various 24" - 90° elbow.(1) Batch various 24" - 45° elbow.(1) Batch 150' - 12" Straight pipe.(1) Batch various 12" various fitting.

MAC 120-MCF-572 High Capacity Baghouse Dust Collection system with Rotary Air Lock (RAL) and Medium-pressure Controlled air cleaning dust Filter (MCF). -- Baghouse Capacity: 50,000 CFM @ 7.2:1 Air-to-cloth ratio (ACR), approx. 6,921 sq-ft of filter area based on (572) Filter bags; 120" long x 5" dia. -- Equipped with: (1) AIR TECH size 402, BISW, Backward Inclined Air Handling Fan, Class IV, with 40" inlet, ground-mounted on unitary base, flanged inlet box & outlet. For prior application fan operating point (RPM/SP) is set up for about 41,526 CFM @ 12" WG at 1566 RPM, drawing 119 BHP. the fan is equipped with a variable volume damper on discharge. Fan range is about 40,000 - 55,000 CFM. Powered by a TOSHIBA 150 HP TEFC, 444T, 1800 RPM motor packaged with a belt drive -- Bag Cleaning: Mac "Never-Miss" Cleaning System with rotating arm, diaphragm valve for pulse cleaning Approx. 3 HP positive displacement (PD) pump for bag cleaning at only 7- 9 PSIG. 1 HP direct drive gear motor for distribution arm, integral manifold/surge tank, pneumatically controlled firing mechanism activating the diaphragm valves/nozzles. When cleaning arm & bag segments are correctly aligned air nozzles fire directly into bags without wasted cleaning air. -- Includes: MAC FS24x24 AIRLOCK Rotary Air Lock (RAL) with approx. 2 HP SYNCROGEAR MODULE gear motor; sprinkler package; 60° Cone-shaped hopper attached to MAC at bottom of cone. -- Features: Floor-standing Electrical controls (excluding shared controls) with MOTORTRONICS Solid State AC Softstart for main 150 HP motor. -- Additional Features: Explosion vents. Summer/Winter diverter and return air ductwork. Support structure. Caged access ladder from ground Service Platform and to the top plenum. -- Baghouse constructed of 7 gauge carbon steel containment; one piece body all welded construction, 180" (15') diameter shell panelized unit, walk-in plenum for maintenance and bag replacement. -- MAC design features: MCF 4HVP Pump package. MCF Medium-pressure air requires less HP and yet offers high dust and air collecting efficiency with unmatched baghouse cleaning at lower operating cost. MCF pulses each bag the same number of times with the same amount of air. (Unlike some competitors which clean the inside rows of bags more often than necessary thus wasting energy, causes uneven pressure drop, and bag wear). -- (2) of these identical units are installed per photos, one only is available based on Owner/buyer agreement and price point. Material handling fan/drive is not included and is assumed to stay with the remaining filter unit. -- Overall dimensions: 580.5" high x178.5" square frame with an estimated weight of filter unit (less structure and accessories) 31,000 Lbs. -- Professional dismantling/rigging, truck loading and transportation are available at extra cost. -- NOTE: Per photo #1 on the Ex-Factory website the unit for sale is on the right-hand side. The left-hand unit is not easily accessible.

MAC/SCHENCK 144-RPT-252 STYLE III Baghouse Filter System with Pulse Jet Cleaning and Rotary Air Lock (RAL) discharge.RPT Filters (Rectangular Pulse Top-Removal) Rectangular top removal bodied filter unit designed to handle high air volumes. • Bags are removed vertically from the top clean section. Walk-in plenum so the filter media replacement and maintenance can occur in an enclosure for inclimate weather. -- Baghouse Capacity: 4,770 sq. ft. of cloth consisting of (252) bags, 144" long 16 Oz P84 Top Load bags and bright wire cages. Depending on your application, for example at an air-to-cloth ratio of 3.14:1 it can develop 15,000 CFM. -- Equipped with: (1) PHELPS FAN, Material Handling, WRM-380 CCW-TAU HD ARR. 8 with A-36 inlet flange Performance at 15,000 ACFM & 15" SPWG, 1780 RPM, 315°F, 0.050 #/cu. ft..500' elev. Direct drive MOTOR IS NOT INCLUDED but was designed for 75 HP, 1800 RPM,, 365T. Fan was connected in a negative pressure configuration, flanged inlet & outlet. -- Bag Cleaning; Requires 33 SCFM of clean, dry air at 90-100 PSIG. -- Complete with: Auger on bottom of hopper feeding Rotary Air Lock (RAL) with approx. 1.5 HP gearmotor at 22 RPM.; (3) Rupture style explosion vents.. -- Features: Equipped for High Temperature (400°F) bags Special equipment includes VITON Diaphragm valves, copper line (in lieu of polyflo tubing)high temperature air header connections and hi-temp purge pipe compression on couplings. (2) 2" NPT couplings with plugs are included in the plenum section for future addition of sprinkler/deluge system. -- Filter unit constructed of carbon steel containment with 3/8" x 4" reinforcing ribs. 34" diam. high entry inlet and top outlet. -- Includes: Nema 4 Timer Board and solenoid valve enclosure. Each require 110/60 Hz power supply. Filter has (2) solenoid valve enclosures. -- Dimensions: 492" overall height (ground to top), 156" square sides. Separates into (3) sections: Top Plenum, filter section and bottom hopper/support steel. -- Dismantling/rigging is included. Please inquire for transport to your location.. -- NOTE: Extra high Stainless Steel stack is available if you want it.

MACDONALD STEEL 65 ST Dust Collector System with Shaker filter cleaning, Rotary Air Lock, and 18' dia. housing. -- Specifications: Capacity for 65,000 CFM, 18' dia. shell, with 8,199 sq-ft. of filter area for an air-to-cloth ratio of 7.7:1. T-150 polyester bags 14 oz. with a 30 - 40 CFM.@ 1/2" WG permeability. -- Current Fan configuration: System 1: Fan inlet of 33" at 32,500 CFM; System 2: .Future capacity for a second fan as per System 1. Return air duct is 42" x 72". -- Filter Cleaning: Top mounted electrically operated & timed mechanical shaker, approx. 2 HP motor which will automatically operate on all shutdowns. -- Equipped with: MACDONALD 18" Rotary Air Lock (RAL) with bottom eductor/T-section for connection to a relay/transfer fan (not included.). -- Complete with Fire Damper, Summer/Winter Damper with Silencer, Explosion doors, safety ladders, and access platform. -- Features: 13" MH/HT 20 HP Transfer/Transport fan -- Overall height is currently 57'-3" with 12' clearance under RAL. Weight of filter with structural steel is 29,000 Lbs plus fan is about 3,000 Lbs. -- Shell panelized construction (made of separable panels allowing for road/Hwy travel).Professional rigging, loading and transportation are available at extra cost; quote upon request.

SIERRA REB 2-250 TWO RAM BALER --New in 2020Specifications per factory: --The Sierra REB-2 two-ram baler was a machine designed by recyclers, for recyclers and is the ultimate machine for any high volume or high production facility. Available with either a 150 or 250 HP power unit, it has the ability to process a wider variety of materials at a higher rate of production and will ensure your return on your investment. The REB-2 has a unique shear blade that works on waste, fiber, non-ferrous scrap metal, and tires, so there is no need to choose between one material or the other. --To eliminate material contamination when changing materials, the REB-2 features an innovative bale eject and oversized bale release door combined with full ejection of bales. This feature also produces better bale integrity, especially on materials with lots of memory. --The standard features on the REB-2 two-ram baler gives it unmatched performance and versatility as well, expertly handling a wide range of recyclable materials:MSWUBCPETOCCONPHigh gradesAluminumNon-ferrous metalsTires MAIN MOTORS: 2 @ 125HP/480V/3PH/60HZ/TEFC• ELECTRICAL SERVICE: 480V 500 AMP• MATERIAL SETUP: 16 MATERIALS WITH 15 BALING PARAMETERS PER MATERIAL (SAVE, RESTORE AND RESET FACTORY DEFAULTS)POWER HYDRAULIC• SYSTEM OPERATING PRESSURE: 4500 PSI• SHEAR/BALING FORCE: 254 TONS• RAM-FACE PRESSURE: 304 PSI• MAIN PUMP FLOW: 564 GPM• PUMP: KAWASAKI PISTON/ VICKERS VANE• OIL FILTRATION: 5µ RETURN LINE, 3µ KIDNEY LOOP• MAIN CYLINDER: 12"; BORE - 254 TONS• EJECT CYLINDER: 8"; BORE - 113 TONS• DOOR CYLINDER: 7"; BORE - 87 TONS• RESERVOIR CAPACITY: 1400 GALLONS

SIERRA - RB6000, ...Baler/Logger - New in 2008 - ElectricElectric with approx 12,500 hoursThe RB6000’s automatic baling and logging cycles keep you at peak efficiency. Baling: 12 - 16 Tons per hourLogging: 18 - 22 Tons per hourAutomobile Logging: 26 - 32 Tons per hourThe RB6000 baler/logger is a beast on automobiles, appliances, and lightweight sheet iron; producing logs with the density you need to meet max weight. Looking to produce mil-spec bales?The RB6000’s cylinder comes within 18 inches of each other allowing you to densely bale clips and busheling to mill specifications.Average Bale and Log specifications:Bales: Size (40 in. X 24 in. X Variable), Weight (850 lbs.)Logs: Size (40 in. X 24 in. X Variable), Weight (1200 - 1400 lbs.)

SIERRA - T715SLK, ...Shear BalerApprox 9,000 Hours Specifications: -- POWER • CUMMINS 6 CYLINDER TURBO DIESEL TIER IV --CYLINDER FORCES • SHEAR, 2 CYLINDERS - 715 TONS • PRE-COMPRESSION - 115 TONS • MAIN COMPRESSION, 170 TONS • FOLDING BOX, 6 CYLINDERS - 270 TONS EACH SIDE --FEATURES • MANUAL AND AUTOMATIC SHEARING, BALING AND LOGGING CYCLES • REMOTE CONTROL • FOUR HYDRAULIC LEGS --HYDRAULICS • REXROTH VARIABLE DISPLACEMENT PISTON PUMP • DENISON VANE PUMP FOR EXTRA SPEED • 150 GALLONS PER MINUTE • MAXIMUM OPERATING PRESSURE OF 4500 PSI • 100% FILTRATION WITH 10 MICRON FILTERS • COMPLETE SYSTEM RELIEF PROTECTION • DIRECTIONAL VALVES ELECTRONICALLY OPERATED • ELECTRIC PANEL WITH PLC • HYDRAULIC OIL COOLING SYSTEM • AUTO-LUBE FOR SHEAR HEAD & PRE-COMPRESSION • HYDRAULIC TANK CAPACITY - 700 GALLONS

SIERRA T556SLK Shear/Baler/LoggerApproximately 5500 hours only!The T556SLK shear/baler/logger was designed with strength, mobility, and time efficiency. It is available diesel or electric and is a true workhorse that doesn’t require a special foundation. After a two-day assembly process, it is ready to work for you. Easily transportable, the SLK series can be easily taken from yard to yard, and there is no need for an operator as they come fully equipped with remote-control operation.With 556 tons of cutting force, the T556SLK Shear/Baler/Logger has unmatched versatility and is ideal for scrap processors, C&D facilities, and Demolition contractors.Shear:Foundry scrap, pipe, beams, plate, HMS #1, HMS #2Shearing production: 16 - 22 tons per hourBale:Clean sheet, wire, lightweight scrap, tin, clipsSize (31"; x 25 x Variable), Weight (900 lbs. average)Baling production: 16 - 22 tons per hourLog:Appliances, automobiles, sheet metal, tinSize (31"; x 25"; x Variable), Weight (1200 lbs. average)Logging production: 18 - 22 tons per hourAs with all Sierra machines, the T556SLK is expertly manufactured with an innovative L-Box-shaped design, 11/16th-inch replaceable abrasion-resistant steel HARDOX "450" liner plates, and outer honeycomb construction, creating greater box integrity.

SIERRA - RB5000, ...Portable Baler/LoggerNew in 2011 - Less than 500 hoursFeatures and Specifications: -- Faster cycle times equals higher production volume. -- Features an easy-to-load loading box that opens to 16’-5"; x 8’-1"; and short-stroke rams that greatly reduce cycle times. These powerful rams crush each load with 240 tons of force per side, producing:Logging production: 16 - 22 Tons per hourBaling production: 10 - 14 Tons per hour -- The "RB5000" is the perfect machine for any scrap yard that receives appliances, sheet iron, smaller automobiles & automobile shells, clips, and busheling as their main source of material. -- The "RB5000" Portable Baler/Logger compresses logs and bales to shredder and mill specifications. -- Typical log density: 25 to 35 Lbs. per cubic foot. Average overall weight: 1400 lbs. -- Typical bale density: 80 to 90 lbs. per cubic foot. Average overall weight: 850 lbs. -- Any transfer station that receives a high volume of appliances and sheet iron can also greatly reduce freight costs by baling and logging. -- The structural details and proper design protect the key components of the "RB5000". -- The solid self-framed construction of this portable baler/logger includes SIERRA’s: Standard L-box shaped design, 11/16th-inch abrasion-resistant steel Hardox 450 liner plates, and outer honeycomb construction creating a greater box integrity and adding to the "RB5000’s" longevity. -- For added versatility, the Crane is independent of the Baler, has a continuous rotation, and is fully operational while the Baler/Logger is in use, increasing productivity. -- The Crane features 24-2/3 Ft. boom length and 4,400 Lbs capacity while fully extended and includes an orange peel grapple with a rotator that was specifically designed to handle bales and logs. The well-designed cab and agronomical controls were designed for comfort, safety, and long-term use.

SIERRA - 700T: Shear BalerSpecifications: -- Motors: (2) Electric 100 HP. -- Preload Table. -- Precompression. -- Shearing: 14 - 17 Tons per hour. -- Baling: 12 - 14 Tons per hour. -- Logging: 15 - 17 Tons per hour. -- Cylinders: (1) Main Compression ram; (6) folding box rams. -- Cylinder forces: Shear - 700 tons precompression; 115 tons main compression; 160 tons folding box; (6) cylinders @ 80 tons each; 240 tons each side. -- Folding Box Dimensions: 19 Ft. x 8 in. x 7-2/3 ft. Open: 19 Ft.; 8 in. x 32 in. x 24 in. Closed: 34 In. x 22 in.Shear Throat -- Disassembled approx. (3) years ago. -- Running when removed from service.

SIERRA - RB6000, ...Portable Baler/Logger - New in 2020Approx 9,300 HoursThe RB6000’s automatic baling and logging cycles keep you at peak efficiency. Baling: 12 - 16 Tons per hourLogging: 18 - 22 Tons per hourAutomobile Logging: 26 - 32 Tons per hourThe RB6000 baler/logger is a beast on automobiles, appliances, and lightweight sheet iron; producing logs with the density you need to meet max weight. Looking to produce mil-spec bales?The RB6000’s cylinder comes within 18 inches of each other allowing you to densely bale clips and busheling to mill specifications.Average Bale and Log specifications:Bales: Size (40 in. X 24 in. X Variable), Weight (850 lbs.)Logs: Size (40 in. X 24 in. X Variable), Weight (1200 - 1400 lbs.)The portability of the RB6000 baler/logger gives you the versatility you need with the capability of being moved to multiple locations or to different areas within the same location.The hydraulic powered outriggers provide the needed stability to handle the heavy weight of the machine.

SMART 60" Pallet Band Dismantler Specifications: -- 60" Bay -- (1) 15 HP Blade Drive Motor. -- Hydraulic powered table lift. -- Adjustable table height to allow the machine to dismantle a range of different heights of wooden shipping pallets. -- New controls

SPEC AIR Model R-44SQ Dust Collector with Shaker Bag Cleaning, Abort Gate, Spark Detection, Rotary Air Locks and Relay Fan in a closed loop configuration. -- Overall Data: 46,000 CFM with approx. 6170 sq. ft. of cloth area consisting of (286) filter bags operating at 7.4:1 Air-to-Cloth Ratio (ACR). 'Can velocity' (upward) is 211 FPM. Polyester filter bags are 9" dia. x 110" long. -- Fan:/Motor: SPEC-AIR EB-44 Clean Air Fan with approx 44" dia. inlet/outlet, ground- mounted in an upblast arrangement. Fan can deliver 46,000 CFM @ 16" SP. Inspection door, and belt guard. Belt-driven by a TOSHIBA 200 HP High Efficiency (Inverter Duty), TEFC motor, 447T frame at 1780 RPM. -- Bag Cleaning: Via (2) Shaker motors with a lattice of tie-rods inter-connected to each row of bags. Bags are accessed from the top clean air plenum.Timer relay from low voltage controls for bag cleaning. -- Comes with: (2) Tapered hoppers separating the large particles, large access door, Backdraft Dampers adapted to (2) 32" filter inlets, lower hopper bottom each with Rotary Air Lock. Discharge from both RAL's is connected to a Material Handling Transfer/Relay fan into an enclosed container (not included) for continuous collection of waste. A return pipe from container makes this a closed loop configuration. Explosion doors. Safety ladder to top return air plenum.. Magnehelic differential pressure gage to monitor the condition of the filter bags. -- Construction: Heavy gage construction with reinforcing ribs and Flange-bolted in the middle easily allows units to transport into two units, ie 120" x 141".Return Air starts from filter outlet with adaptor to 44" dia. fan inlet. Discharge Silencer of fan outlet has a 44" Abort Gate returns air into building. -- Features: HANSENTEK Spark Detection system. Main electrical panel with pushbottons and controls. -- Includes: Filter housing and outside pipe is fully covered with insulation to minimize heat loss & reduce plant heating cost. -- Overall dimensions: 282"; Long x 120"; Wide x 317"; High. Weight approx. 20,000. Lbs. -- Note: Unit was moved in 2020 to current location, refurbished added installation.

SPEC AIR Model R120-26RD-OC Baghouse Filter Auto Shaker Type Dust Collector Loaded with features. -- Capacity of approx.15,500 CFM and the following features and components: -- EB-26, 60 HP SPEC AIR, Air Handling Fan , 15.500 CFM @ 16" SP mounted in a negative pressure configuration (clean air side) with return air and with automatic 26" dia. Abort Gate Damper according to NFPA-68-69 CODE. 110 volt actuated by the Spark Detection System. -- HANSENTEK AN104 Spark Detection/Suppressions system Per NFPA 64-68 and c/w BPS-9X4 Booster Pump & FLEXCON P2P20 Tank. -- 1,961 sq. ft. of filter area using (97) high efficiency Polyester bags. Operating at 7.9 to 1 ACR (Air to cloth ratio). -- 26"; Diameter Inlet & outlet duct. -- Tangential inlet with Backflow Damper, according to NFPA-68 CODE. -- Top mounted motorized bag shaker. mechanism powered by 1.5 HP. -- Rotary Air Lock with 96" clearance. (4) leg support steel frame & Safety access ladder. -- Explosion Venting Doors, according to NFPA-68 CODE. -- Filter Bag size approx. 9" dia. x 9' long, -- Inline 26" dia. Silencer muffler on return air duct. -- Ground mounted Belt Driven Fan complete with TEFC motor and inspection door. -- Features: 60 HP Soft Start Controller. -- ENGINEERED ELECTRIC Control Panel with starters and controls. -- Manometer gauge to monitor differential pressure (life) of filter media. -- Housing/Support Steel dimensions: 120" long x 120" wide x 32' high. Approx. 13, 500 Lbs. -- Some pictured pipe is included.

SQUARE D - 75T3H, ...75 KVA, 480 - 208 V, 3-Phase Autotransformer Specifications: -- Intended for power, heating, and lighting applications. -- Enclosure Rating: NEMA 2. -- Multi-Tap (432 - 504 V) Primary 480 V (Delta); Secondary 208Y / 120 V @ 60 Hz ventilated. -- Aluminum windings. -- cULus Listed. (2) Available; price per unit. - Make offer for both!

SSI Model - 1000-E, Slow Speed, High Torque ShredderSpecifications: -- 50 HP Motor; twin shafts; 40" x 25" ChamberIncludes: -- Stand, feed hopper; controls

STAR V MACHINERY SCG-1600 AUTOMATIC CROSS GROOVER:: -- Specifications:(1) Spindle with 12 HP - 3,600 RPM motor, 60" max. crosscut cap., material thickness 0.25" - 1.125". (1) Internal 60" Stroke Tape Applicator Station. -- 96" Stroke Servo Motor Driven Rear Pusher Fence (Full 60" Rear Table Width), 96" Long x 20" Front Table with 5 Digital Manual Stops. -- Rear Fence Movement, Cutter forward Speed Cut/Tape Stroke and All Controls for Start/Stop, On/Off, Axis position Displays on 10" Touch Screen Panel HMI. -- Grooving Head up & down movement via pneumatic cylinder with linear rail & linear bearings, depth fine adjustment with special threaded adjustable unit. -- Carriage cross-travel powered by a 3 HP hydraulic motor (4GPM), driven ball screw with linear rail & linear bearings; feed rate from 0 - 40 FPM; Heavy Duty welded frame construction. -- Complete with:Safety guards and cutter guards; pneumatic support fence; (1) heavy-duty in-feed/out-feed roller tables. Available Options at additional cost:ACCESSORIES, TOOLING AND TAPE "CHOOSE AND ADD TO MACHINE BASE PRICE" Cove Corner Plug Jig $575.00 ea. Brazed Carbide 90 Degree Cutter for up to 1/2" Solid Surface $745.00 ea. Please specify the Material Brazed Carbide Cove Backsplash Cutter for 1/2" Solid Surface $1,265.00 ea. Please specify 3/8" or 1/2" Radius Brazed Carbide 90 Degree Cutter for up to 3/4" Wood Materials $940.00 ea. 90 Deg. Insert Cutter for up to 1/2" Thick Material (Body Only) $1,265.00 ea. Requires Below Inserts90 Degree V Insert for up to 1/2" Thick Material, $32.00 ea. Minimum of 12 Inserts Required $384.00 Carbide Insert Cove Backsplash Cutter Head for 1/2" Material (Body Only) $1,590.00 ea. Please specify 3/8 or 1/2 RadiusRequires Below Inserts 3/8" Cove Radius Insert for 1/2" Thick Material $42.00 ea. Minimum of 12 Inserts Required $504.00 3/8" Double 45 Degree Insert for 1/2"Thick Material $42.00 ea. Minimum of 12 Inserts Required $504.00PCD Diamond 90 Degree Cutter for up to 1/2" Thick Material $3,485.00 ea. PCD Diamond Cove Cutter with 1/2" Radius for 1/2" Thick Material $5,645.00 ea. Roll of VAC2MG, 2" (50mm) wide 1025y (937m) long Roll V Groove Tape $245.00 ea. Minimum of 3 Rolls per order = $735.00 -- Actual Model is STAR V MACHINERY SCG-1600 AUTOMATIC CROSS GROOVER:

STAR V MACHINERY SLG-2000 36 LINEAR V-GROOVER: -- Specifications:Working table dimensions are 120" long x 36" wide; Working width from 6" - infinite" (152 - infinite mm); Working length from 20" - infinite (508 - infinite mm); Working thickness from 0.25" - 1.15" (6 - 29 mm).Maximum throat clearance for linear & crosscuts is 14.5"/24.5" (355/622 mm). -- Equipped with: (2) Independent, 10 HP - 3,600 RPM Saw Motors with "servo" control adjustment in "Y" axis & manual "Z" axis adjustment.30 mm Dia. Arbor x 76 mm (3") clamping length to accommodate wider cove backsplash, triple-fold profiles, or using it for hogging and finish cut; 9.25" (235 mm) max. Cutter-head dia.1-Saw motor is mounted on the front & 1-Saw motor is mounted on the back of the 8" x 12" x 1/2" heat-treated steel heavy-duty overhead support beam.Side-to-side head travels via linear rails & bearings, manual head height adjustment via linear rails & bearings. -- Feeding System:(1) 3 HP Variable speed drive belt system with "servo" height adjustment; Feed rate from 0 - 45 FPM (12 MPM), belt feeder moves workpiece on a precision "aluminum" roller table; -- Tape Applicator: (2) Automatic Tape Applicators with "servo" adjustment, according to the Saw motor position in "Y" axis. -- Operator Interface:10" HDMI Touch Screen Display for Start/Stop, On/Off, Feed Speed & Axis Position. -- Complete with:; Safety guards and Cutter guards. Anti-Kick-back Device. Emergency Shutoff line. Dust collection requirements 4,200 CFM, collector outlets on cutter guards 5" in dia. -- Actual model# is STAR V MACHINERY SLG-2000.
