SCM SANDYA - 40 M3 135, ...3-Head Wide Belt Sander 52" Width cap. Drum, Drum, Combination HeadHead Configuration:1st Head: Steel Contact 22 kW Pneumatic blowdown and alignment.2nd Head : Rubber Contact 18.5 kW Pneumatic blowdown and alignment.3rd Head: Combination Platen 15 kW Pneumatic blowdown and alignment.Note:The SCM sander does not have a brush. After the 3rd head, it has this pneumatic blow-off bar with multiple blow-offs running the length of the sanders width. Sander can be seen under power if needed.Specifications: -- 53" x 103" Abrasive belts with electronic tracking. -- All heads with abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 5 HP motor. -- Automatic part thickness adjustment. -- Motorized thickness opening via (4) precision conveyor bed jacks with LED readout. --0" - 7-7/8" opening. -- Equipped with & Features -- Outfeed rubber covered holddown rolls or shoes on all heads. -- Motor load meters. --Infeed and outfeed conveyor extensions. -- WYE-DELTA soft start.Note: The SANDYA model "40" is more or less the same as the SANDYA "30" but more Heavy Duty.

SCM SANDYA 15S (3) Head Wide Belt Sander42" Width cap, Drum, Drum, Combination HeadHead Configuration:1st Head: Steel contact roll, 7" dia., 35 HP motor;2nd Head: Rubber-covered contact roll, 24 HP motor3rd head: Combination head, rubber-covered contact roll (45 Shore) and 3" wide finishing platen, 17.4 HP motor.Specifications: -- 43" x 103" Abrasive belts -- Electronic tracking & pneumatic belt tensioning, abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 4 HP motor -- Automatic part thickness adjustment -- Motorized thickness opening via (4) precision conveyor bed jacksEquipped With & Features: -- LED readout, 0" - 6-1/4" opening. -- Infeed & outfeed spring loaded rubber covered hold-down rollers -- Motor load meters -- Infeed and outfeed roller conveyor extensions.

SCM Sandy 10 -RCS-110 Wide Belt Sander (2) Heads43" Width cap. Drum, Combination HeadHead Configuration:1st. Head: 7" diameter corrugated metal roller for calibration 35 HP ( Drives both Heads )2nd Head: Combination head with 7" dia. contact roller (spiral grooved rubber covered); air/jump finishing platen controlled with timers to eliminate any rounding on leading & trailing edges of the panel, 2" wide platen.Specifications --103" long x 43" wide Abrasive belts --Air tracking, floating & rigid bed for sanding of veneers & solid panels; infeed & outfeed spring loaded holddown rolls -- Minimum workpiece length 16" --Thickness capacity 6.25". --Separate 2.5 H.P. variable speed feed motor delivering feed speeds from 15 to 70 FPMNote: The seller has 20 boxes of various sandpaper belts (80 – 150 grit) that will be included.

SCM SANDYA 10/S M2 2-Head Wide Belt SanderHead Configuration1st Head: 7" Diameter Spirally-grooved steel contact roll, 20 HP Motor.2nd Head: Combination head, 7" Diameter Spirally-grooved rubber-coated contact roll, Finishing platen with Electronic sectional pad with EPICS System, 3-1/2" Steel contact roll, 13 kW (17-1/2 HP) Motor.Specifications: -- 4.5 - 9 m/min (15 - 30 FPM) Variable feed speeds, -- Part thickness 4 mm (0.2") to 170 mm (6.7"). -- 43" W x 103" L Abrasive belt, Electronic sanding belt tracking & Pneumatic belt tensioning. -- 34" H Natural rubber feed belt,Equipped with & Features -- Automatic thickness adjustment, Automatic feed belt tracking & Tensioning, -- Motorized rise & fall of working table, -- Part thickness & Conveyor belt speed LED readout, -- Infeed safety bar for operator protection and oversized parts. -- 3" Diameter Entry & exit rolls, 13" L 2-Roll Infeed & Outfeed extensions with 2" Diameter Rollers & Manifold. -- Unopened box of (10) KP520 100 Grit Belts (Purchased for $500).Dimensions: 88" L x 86" W x 90" H.Weight: 4,440 Lbs.

SCM SANDYA 7 RCS Wide Belt Sander2-Head, 42" cap. - Great solid wood finish Sander. -- 1st Head: Grooved steel contact roll, 6-1/4" dia., 30 HP motor -- 2nd Head: Combination head, rubber covered contact roll, 6-1/4" dia. (65 Shore), and 2" wide finishing platen, 25 HP motor. -- 43" x 75" or 85" Abrasive belts with electronic tracking & pneumatic belt tensioning, pneumatic exclusion of all contact rolls. -- Conveyor belt feed with variable feed speed, 14.5 - 30 FPM, 1.5 HP motor, automatic part thickness adjustment, -- Motorized thickness opening with LED readout,0" - 6-1/4" via (4) precision conveyor bed jacks. -- Infeed & outfeed spring loaded rubber covered holddown rolls on all heads, -- Motor load meters, infeed and outfeed conveyor extensions, WYE-DELTA soft start.

SCMI - Sandya 3S/ RCS: 37" Double Head Wide Belt Sander37" Width cap.; Drum, Combination Head.1st Head. 4-1/2" Diameter steel contact drum with: Manual grit set.2nd Head. 4-1/2" Rubber drum with: 2" Wide soft platen.Specifications -- 30 HP - 230 V - 3 Ph Drive. -- DELTA Soft start motor controls. -- Electrical requirements: 91 Amps. -- Anti-dubbing control of platen; rise-fall to protect leading & trailing edges of panels. -- Variable speed conveyor by: Inverter, 12 - 60 FPM with: Digital display for working height. -- Automatic thickness set up. -- 6-1/2" Max. thickness capacity.Equipped with & Features -- Automatic conveyor belt tracking (pneumatic cylinder). -- (2) Platens; soft (for veneer); semi-stiff (solid wood). -- 50 Durometer conveyor belt. -- 2-Roller infeed & outfeed roller tables. -- (4) Top & Bottom fastened jack screws. -- Manual adjustment of contact roller & platen positions; 1,800 CFM. (2) 5" Dust Ports.

DMC SD 60 - TWO HEAD WIDE BELT SANDERSpecifications -- Grooved rubber coated pressing rollers before and after working unit -- 2HP variable speed feed motor 3.5-18 m/min (12-60 FPM) -- Y-Delta two-stage reduced voltage starter on main motor -- Automatic Electronic Table Positioning Device -- In-feed / Out-feed extended tables for easier part feedingEquipped with & Features -- Pneumatic On/Off selector of both rollers and pad -- Adjustable sanding drum and pad position for micro precision adjustment -- Electronic digital thickness readout of work table position -- Powered table lifting by means of four heavy duty motor and lifting columns double fastened at both top and bottom of the lifting columns to provide exceptional table stability -- Electronic tracking of abrasive belt -- Pneumatic belt tensioning with center fulcrum to compensate for tapering of abrasive belt -- Front and rear emergency stop button -- Amperage meter for main motors allows maximum utilization of available horsepower -- Main disconnect switch with the ability to be locked out by padlock -- In feed flexible steel hold down, and anti-kickback plate50 shore, negative profile (waffle style) rubber feed mat -- LOGIC 50 K Electronic Programmer for timing/anti-dubbing of the padSome spec's need to be verified

SCM - S 52, ...Straight Knife Planer20" Width cap.; knife cutterhead; 9 HP main motor (approx.); 1/8" to 9-1/4" motorized opening with mechanical digital readout; max. depth of cut 5/16"; 10" min. length of workpiece; (4) feed speeds at: 21 - 32 - 42 & 55 FPM; table size: 20-1/2" x 33-1/4". -- Equipped with: Chip breaker; sectional grooved infeed & solid outfeed roller.

SCM S 630 K Planer with Tersa HeadSpecifications: -- 24" Width cap.; 12 HP main motor, 2 HP feed motor; 4-3/4" dia. with reversible knife TERSA Planer Head rotates @ 4,500 RPM; -- 1/8" - 11-3/4" Thickness opening via motorized bed with LED readout for fine adjustment. -- Max. depth of cut 5/16"; 10" min. length of work piece; variable infeed speed from 20 - 56 FPM.Equipped with: -- 20-3/4" x 39" Cast iron table, sectional chip breaker, sectional grooved infeed & solid outfeed rollers, adjustable bed rollers. -- neoprene out feed rollersComplete with: -- Magnetic starter and dust hood w/6" dia. dust outlet.Owner states: Condition- like new 24" thickness planer- third owner in a one man shop. Machine has seen very few hours of operation.

SCM Minimax T-50 Tilting Spindle Shaper -- Specifications: -- 1-1/4" Dia. interchangeable spindle tilts -5° to +45°, -- 6.6 HP motor; 3-1/2" cap. under nut, (4) spindle speeds of 1,700 - 4,000 - 7,000 & 9,000 RPM. -- Table size 18" x 43" with adjustable side extension tables; 3" - 5" - 7" & 8" table insert openings -- 4-1/2" max. spindle height above table -- 2" max. tooling retraction under table with 7" max. tooling dia.; working height 37".Equipped with: Outrigger Sliding Table, micro-adjustable fence, spindle lock, magnetic starter w/overload protection, reversing switch, and 4-3/4" dia. dust outlet. Includes: Several New Cutter-heads

SCM T 160 TILTING SPINDLE SHAPER9 HP Main motor, (5) speeds of 2,900 - 4,400 - 6,000 - 7,800 & 10,000 RPM (..but currently with single speed 6,000 RPM pully only!); 1-1/4" dia. interchangeable spindle, 7" spindle length with 4-3/4" motorized vertical spindle adjustment, 9" max. height above table. -- Features: 0° - 45° Motorized tilting, degree tilt gauge, spindle height gauge; max. insert opening 16-1/2", and 39" x 40" table size. -- Complete with: Adjustable fence, mechanical spindle brake & lock, dust hood & reversing switch; NOTE: 3-ROLL FEEDER IS NOT INCLUDED

SCMI T-130 Shaper -TL Tenoning Table Version w/STEFF 2048 FeederSpecifications: 1-1/4" Dia. spindle and a full set of throat plates, 9 HP belt drive motor with (5) spindle speeds of 3,000 - 4,500 - 6,000 - 7,000 & 10,000 RPM; -- 6" Max. cap. under nut; (5) table insert rings, 13-1/2" max. insert opening. -- 47" x 28-1/2" Cast Iron sliding table w/slot for miter gauge.Complete with: Reverse rotation switch, digital height readout, adjustable fence assembly, miter gauge, dust hood with 4" pipe connection. --Mechanical spindle brake, spindle locking foot pedal, TL tenoning table for tenoning-profiling.Includes: STEFF "2048"POWER FEEDER (230 V / 3 Phase), Operating Manual.

SCM - M3: Multi-Blade Dip Chain Gang Rip SawSpecifications -- Width cap.: 300 mm (11.81"). -- Max. depth of cut.: 110 mm (4.33"). -- Throat depth: 8-3/4". -- Min. stock length: 390 mm (15.35"). -- Blade diameter: 200 - 350 mm (7.87" - 13.78"). -- Arbor dia.: 70 mm (2.76"). -- Table size: 750 x 1,530 x 750 mm H (29-1/2" x 60.24" x 29-1/2" H). -- Blade speed: 4,200 RPM. -- Feed speeds: 6 - 48 MPM (19 - 157 FPM).Equipped with: -- 44 kW (60 HP) - 3,554 RPM Blade motor. -- Variable speed drive feed chain motor. (2) Upper infeed & (2) Upper outfeed 4" Dia. rollers; automatic chain lubrication. -- Top & Bottom anti-kickback fingers. -- Main dust hood with: 200 mm (7.87") Dia. outlet. -- Adjustable infeed fence: 40"; x 2-3/4"; H. -- Motor load meter.NOTE: Some spec's need to be verified . NO FENCE

SCMI - STARTECH 29: Construction Boring MachineSpecifications -- 29-Spindle boring head (aluminum alloy single block); drills vertically from top & horizontally from rear. -- Manual tilt with: Gas shock cylinder assist; positive stop at 45° for boring at an angle. -- 3 HP - 3,400 RPM Motor. Equipped with: -- 6-Position turret depth stop; 2-3/8" boring head stroke with: Digital readout setting; hydraulic brake for vertical "through boring." -- (3) Air holddown clamps; foot pedal operated. -- Index pins for: Line boring; side fences.

SCM TECH Z 30 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications:Working Field "X" axis 120" (3,050 mm); "Y" axis 52.7" (1,340 mm) for routing & 44" (1,118 mm) for boring; "Z" axis stroke 7.8" (200 mm); max. material thickness 3.9" (100 mm). -- Positioning Speed:"X" & "Y" Axes are 197 FPM (60 MPM); "Z" axis is 72 FPM (22 MPM).Axes positioning by: AC Brushless motors and YASKAWA drives; high precision ball screw drive system in "X", "Y". "Z" Axes;All axes ride on prismatic guideways & sliding blocks. -- Worktable:(6) "TV" Tubeless mobile support rails, (2) vacuum pods per rail; (4) pneumatic lifter rails for heavy panels.(6) Pneumatic pop-up backstops, (6) pneumatic pop-up front stops; (2) pneumatic pop-up side stops.LED Display positioning assistance for the support rails & vacuum pods; (2) independent working fields. -- Boring Head:3 HP (2.2 kW) motor - 4,000 RPM; (15) independent vertical spindles: (8) Spindles in "X" & (7) spindles in "Y".(6) Horizontal spindles (2 + 2) in "X" & (1 + 1) in "Y-axis".(1) X-axis grooving saw with 100 mm dia. blade - 6,000 RPM. -- Machining:(1) 10 HP (7.5 kW) Electro-spindle router with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM, max. torque achieved at 12,000 RPM.Static inverter for stepless speed & rapid shutdown rotation.(1) 6-Position ATC tool plate mounted on the on the machine for "on the fly" ATC; max. tool weight is 8 kG (17.6 Lbs). -- Operator & Machine Control:PC Front-End with: SCM "UNIVERSAL K2" + "Xilog Plus" + Windows "XP" Pro Operating System; 15" CRT color display, CELERON 2 GHz processor, enclosed in air-conditioned cabinet. -- Complete with:(1) 100 m³/Hr Vacuum Pump; automatic lubrication system; "BUMP STOP" safety system. -- Actual Model is SCM TECH Z30 R6

SCM - Concept 2000, ...Double End Tenoner.Double End Tenoner with: Jump scoring, Hogging, Shaping with stacked tooling. -- 122" Opening cap., motorized opening with keypad entry & LED readout, 12" infeed chain area in front of holddowns. -- 0" - 4" Motorized thickness opening with mechanical digital readout. -- 6" Min. width, 2-post machine. Each side equipped with: -- 1st Station: Jump scoring. -- 2nd Station: Hogging unit. -- 3rd Station: Coping head with stacked tooling capacity (manually operated). -- 4.5 HP Drive for 10 - 60 FPM variable feed speed. -- Chain dogs on 15-3/4" centers, rubber top nonmarring chain pads. -- Heavy-Duty chain links with: Needle bearings, automatic oil mist chain oiler, automatic brake on feed motor with emergency stop.Complete with: -- Upper driven holddowns with: Continuous feed belts; feed beams can be disengaged for conventional part feeding in front of dogs. -- Mobile remote control for setup; dual lead screw for traversing beam; exhaust hoods on all heads.Note: Tear down and loading not included.

SCM PRATIX S-15-B FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:Single 5' x 12' traveling "Bridge Gantry" and stationary aluminum dual vacuum table with a MATRIX square grid pattern for fixturing parts.Grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining".(8) Part location pop-up pins mounted on the table perimeter. -- Working field:"X" Axis is 145.11" (3,686 mm); "Y" axis is 61.2" (1,555 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness 4" (100 mm). -- Positioning Speed:"X" & "Y" Axis 115 FPM (35 MPM); "Z" axis at 82 FPM (26 MPM); closed loop AC Servo drive system.High precision "Rack & Pinion" system in "X" & "Y" axis & ground ball screws "Z" axis; all axes ride on extra large precision profile linear guideways. -- Boring Unit:3 HP (2.2 kW) - 6,000 RPM motor; (7) vertical spindles on 32 mm centers, (5) in "X" axis & (2) in "Y" axis. -- Machining:(1) 9 HP (6.7 kW) Air-cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 14-Position ATC tool rack mounted to the machine base. -- Operator & Machine Control:PC Front End with: "XILOG Plus" + Windows "XP Pro" Operating System; 17" high resolution LCD; ergonomic keypad.USB Ports, serial ports RS-232 & RS-242 & Ethernet adaptor; programs can be transferred via disk or downloading by wire is possible.All computer components are mounted on a mobile stand.XILOG Plus Offers: Incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally equipped with:Onboard mini-CAD with built-in programming for writing circles, ellipses & angles with only a few keystrokes; Onboard cycle optimization, onboard calculator, mirror-imaging, and repeat imaging. -- Complete with:(1) 300 m³/Hr Vacuum Pump; external transformer 208/230/480 Volt; safety enclosure around the spindle carriage; tool length probe sensor; manual centralized lubrication.Includes: (1) Universal Remote Pendant, 7" color display allows for the effective management of all machine functions from manual Jog Mode to loading & execution of a program.The pendant is fitted with a USB port to allow quick load & setup of new programs; safety "bump-stop" bumpers; emergency stop rope & manuals. -- Actual Model is SCM - PRATIX S-15-B.

SCM - PRATIX S-15-C: Flat Table Machine (w/ATC/Boring) + Rake -- SpecificationsSingle 5' x 12' traveling "Bridge Gantry"; stationary aluminum dual vacuum table with: MATRIX Square grid pattern for fixturing parts.Grid pattern allows use of: Vacuum pods or closed cell rope gasketing material; use of spoil boards for "nested base machining".(8) Part location pop-up pins mounted on the table perimeter. -- Working Field"X" Axis: 145.11" (3,686 mm); "Y" axis: 61.2" (1,555 mm); "Z" axis stroke: 9.8" (250 mm); max. material thickness: 4" (100 mm). -- Positioning Speed"X" & "Y" Axis: 115 FPM (35 MPM); "Z" axis: 82 FPM (26 MPM); closed loop AC Servo drive system.High precision "Rack & Pinion" system in "X" & "Y" axis; ground ball screws "Z" axis; all axes ride on extra-large precision profile linear guideways. -- Boring Unit 3 HP (2.2 kW) - 6,000 RPM motor; (12) vertical spindles on 32 mm centers: (7) In "X" axis & (5) in "Y" axis. -- Machining(1) 11 HP (8.2 kW) Air-cooled electrospindle with: HSK F63 Adaptor; variable spindle speeds from: 1,500 - 24,000 RPM.(1) 14-Position ATC tool rack mounted to the machine base. -- Operator & Machine ControlPC Front-End with: "XILOG Plus" + Windows "XP Pro" Operating System; 17" high resolution LCD; ergonomic keypad.USB Ports; serial ports RS-232 & RS-242; Ethernet adaptor; programs can be transferred via disk or downloading by wire is possible.All computer components are mounted on a mobile stand.XILOG Plus Offers: Incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration; encoder feedback; dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally equipped with:Onboard mini-CAD with built-in programming for writing: Circles, ellipses & angles with only a few keystrokes; onboard cycle optimization; onboard calculator; mirror imaging; and repeat imaging. -- Complete with:(2) 6.4 KW/8.5 HP Vacuum Pumps; external transformer 208/230/480 Volt; safety enclosure around the spindle carriage; tool length probe sensor; manual centralized lubrication.Includes: (1) Universal Remote Pendant; 7" color display: Allows for the effective management of all machine functions from manual Jog Mode to Loading & Execution of a program.Pendant is fitted with: USB Port to allow quick load & setup of new programs; safety "bump stop" bumpers; emergency stop rope & manuals. -- Options IncludeAdditional items pictured are included with this machine. -- Actual Model: SCM - PRATIX S-15-C

CMI - SI 400 E: Sliding Table Panel Saw with motorized adjustmentsSliding Table Panel Saw with Motorized Blade adjustments and powered Rip Fence positioning.Specifications -- 3,200 mm (126") Stroke length; anodized aluminum: 14-1/4" Wide sliding table; 2-position table locks for easy panel loading in any position. -- 45° Tilting - 1" dia. main saw arbor: 400 mm (15.8") Blade dia. cap.; 130 mm (5") max. cut height @ 90°; 90 mm (3.1") @ 45°; 59" rip capacity. -- 9 HP Main Saw with self-braking motor: (3) Cutting speeds: 3,600 - 4,800 & 6,000. -- 1.0 HP Scoring Saw Motor: 3/4" Dia. arbor; 120 mm (4-11/16") dia. split scoring blade - 8,500 RPM; scoring unit w/external adjustment with stops. -- Electric control for blade group: Raise, lower and tilt. LED readouts and separate controller to position rip fence accurately with: Fast/slow control to accomplish the left & right movement.Equipped with: -- Articulating overarm protection guard; Heavy-Duty tubular steel support; dust guard. -- 41" x 25" Fixed table size; square crosscut fence with: (1) Stop; extension table with: Miter fence & sliding outrigger support. Includes -- (1) 5" & (1) 4" Dust outlet; centralized control panel with magnetic controls; safety micro switches on access panels & doors. -- Control panel programmable: SCM EP 300.Overall dimensions: 280" x 165" x 36"; Net weight approx.: 2,200 Lbs; requires dust collection of: 1,100 CFM.

US CONCEPTS CHB 12 HauncherThe CHB-12 Hauncher-Notcher is designed to notch along the edge of the board or across the end.Typical applications: Box joints, finger joints, bee boxes, hinge notches, coping, profiling in furniture and window industries, decorative cuts, beaded frame cabinets, toe kick notches, etc. Equipped with: a 40 mm horizontal spindle that moves up hydraulically past the table with the clamped material. -- A backup board in the table and climb cut ensure the clean-cut, even on cross grain. -- Material air clamps and spindle motion are actuated by a foot switch. Specifications: -- Spindle Dia. 40 mm, Spindle Length 12". (Also available in 16" & 20" capacities) supported on both ends; -- Max. Cutter Dia. 10" (254 mm); max. Cutting Depth 2-1/2" (64 mm); max. Material Stacking Height 8" (200 mm). -- Spindle Speed 4,300 or 6,200 RPM; Feed Speed (Air/Oil) 0 - 25 FPM; 15 HP motor; Dust Outlet 2 x 6" (150 mm).Complete with: -- (2) Air Clamps, Back Fence, Side Pivot stop, and Stop Bar. -- Table Size 36" x 16"; Machine Weight 1,650 Lbs (750 kG). -- OPTIONS: Electric; 20 or 25 HP motor; Additional Air Clamps; Additional Side Stop; Center Fence mounted to the Table; Horizontal Clamps; Extended Stop Bar. -- Other Options: Fixture for 45° Cut (Mitered cabinet Doors or Stretcher Bars).
