CAM-WOOD - VPS APL , ...Vertical Saw w/Scoring & Panel Lifting ClampsCapacity: -- Top to Bottom cutting height is 82-1/2" (2,100 mm) without scoring and 78-3/4 (2,000 mm) with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length "rip cut from left/right" is 161.417" (4,100 mm); cuts single or stacked panels up to 1-7/8 (50 mm) in thickness. Equipped with: -- 4 HP Motor; 250 mm (10") dia. x 80-tooth x 30 mm bore main blade; separate 3.15" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine to Hardwood. -- 2-Motorized panel lifting clamps "grab panel on top edge" for bottom cuts, clamps travel on (2) vertical screws for positioning of panels (660 Lbs. cap). -- (2) LED Readouts, (1) for crosscutting at the middle of the frame and (1) for horizontal rip cuts; (2) flip stops for crosscut measuring, one located on the bottom rail and the other on the mid-height measuring rail. Complete with: -- Foldout shelf at the middle of the frame for small part cutting; automatically shifting material back support grid shifting away from the saw blade cut-line prevents cutting into the grid support strips while rip cutting horizontally. -- Precision ground bottom edge support rollers to facilitate easy loading & positioning of the larger or heavy panels; standard inch preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- Rip gauge for repeat (same size) rip cuts and (3) adjustable preset stops; material always rests firmly against the "angled" back grid support. Includes: -- Spring-loaded floating saw blade enclosure shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- (1) Main blade; (1) scoring blade.

CAM-WOOD - VPS I +: Vertical Panel Saw (76" x 122" w/Scoring); Vertical/Horizontal Digital Readouts & Auto-Lock SystemTop to Bottom cutting height : 2,000 mm (76") with or without: Scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 3,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness.Standard Features -- 4.0 HP Motor (5-1/2 HP Option) with: 250 mm (10") dia. 80-teeth main saw blade. -- Separate 80 mm (3.15") dia. scoring blade; belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto shifting material back support grid; shifting away from the saw blade cutline prevents cutting into the grid support strips while rip cutting horizontally; senses the blade/cutter position & automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading & positioning of the larger or heavy panels; both standard inch & metric preset "beam lock" stations. -- Vertical Cutting Stations: Spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- (2) Adjustable flip stops on inch (metric available) measuring scales: (1) Located on the lower rail & the other on the foldout shelf at the middle of the frame. -- Repeat Rip Gauge for duplicating multiple horizontal cuts. -- Retractable Material Support Shelves throughout the entire length of the machine frame allow ergonomic cutting of smaller parts, at any cutting station without the need for the Operator to bend down.Includes: Vertical/Horizontal Digital Readouts; Pneumatic Lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth; 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth; 20 mm bore scoring blade.Optional Equipment available. Built-in Dust Collector: Please add ...$ 1,250.

CAM-WOOD - VPS AV, ...CNC Fully Automatic Vertical Saw w/Scoring & Panel Lifting ClampsPC Control Panel with Software Optimizing Panel Cuts, Automatic Positioning System; the machine automatically switches to the vertical and horizontal position by Automatic Positions System.Capacity: -- Top to Bottom cutting height is 82-1/2" (2,100 mm) without scoring and 78-3/4 (2,000 mm) with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length 161.4" (4,100 mm); cuts single or stacked panels up to 1.57" (40 mm) in thickness. Equipped with: -- 4 HP Motor; 250 mm (10") dia. x 80-tooth x 30 mm bore main blade rotate at 5,800 RPM; separate 3.15" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine to Hardwood. -- 2-Motorized panel lifting clamps "grab panel on top edge" for bottom cuts, clamps travel on (2) vertical screws for positioning of panels (660 Lbs cap.). -- (2) LED Readouts, (1) for crosscutting at the middle of the frame and (1) for horizontal rip cuts; (2) flip stops for crosscut measuring, one located on the bottom rail and the other on the mid-height measuring rail. -- Programmable Panel Drive System with +/- 0.1 mm accurate positioning to preprogrammed lengths. Complete with: -- Foldout shelf at the middle of the frame for small part cutting; automatically shifting material back support grid shifting away from the saw blade cutline prevents cutting into the grid support strips while rip cutting horizontally. -- Precision ground bottom edge support rollers with double bearings to facilitate easy loading & positioning of the larger or heavy panels; standard inch preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- Rip gauge for repeat (same size) rip cuts and (3) adjustable preset stops; material always rests firmly against the "angled" back grid support. -- Spring-loaded floating saw blade enclosure shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- Includes: -- Automatic Lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 125 mm (4.92") dia. 24-tooth, 20 mm bore scoring blade.Optional label printer available for additional cost.

CAM-WOOD TX-E8V Automatic Vertical Panel SawSpecifications: -- 98-1/2" Cutting length (cuts vertically top to bottom), adjustable depth of cut up to 2-3/8", 12" blade dia. with 1" dia. bore, single blade scoring; 5 HP main motor.Equipped with: -- Manually positioned pusher fence with grippers; precision ground guide rod, made from medium carbon steel coated with hard chrome, provides smooth and accurate travel. -- (3) Cutting modes: Standard, trim & cutoff to permit clean burrs, repeat cutting mode; heavy gauge base frame & table rest is welded from cold rolling steel plate, offering rugged construction. -- The uniform holding pressure through the entire pressure beam is achieved through a linkage mechanism, ensuring synchronized cylinder actuation on both sides. Flexible saw stroke adjustment enables the operator to select the desired stroke either full way or run out panel return depending on the panel length to be cut, this reduces considerable cycle time. Complete with: -- Fence made of cast iron and the surface precision ground is fitted with a flip-over stop for convenient repetitive cutting; saw carriage runs with bronze wheel, which is CNC lathe precision machined or accurate concentrically producing fine smooth surface cut; the guide rods, hard chrome-plated, provides rigid support for saw carriage; the ripping accuracy is guaranteed. -- 1 HP drive, variable speed saw carriage, cuts 16 - 98 FPM; return speed 98 FPM. Includes: -- Dust chute is covered with a split rubber to form a totally enclosed dust collection system, and fully prevents the hose from being broken resulting from its fatigue. -- Sectional dust guard not only acts as a surrounding saw blade guard but also fully prevents sawdust from spraying out of the machine.

CAM-WOOD TX-C8VX Automatic Vertical Panel Saw (Servo Gripper)Specifications: -- 98-1/2" Cutting length (cuts vertically top to bottom), adjustable depth of cut up to 2-3/8", 12" blade dia. with 1" dia. bore, single blade scoring; 5 HP main motor.Equipped with: -- PLC Controlled automatic pusher fence with grippers with Auto Stops or Auto Program Sizing mode; 40 FPM pusher speed, +/- 0.004" accuracy; precision ground guide rod, made from medium carbon steel coated with hard chrome, provides smooth and accurate travel. -- (2) Cutting modes: Standard cutting & scoring pass and cutting; the heavy gauge base frame & table rest is welded from cold rolling steel plate, offering rugged construction. -- The uniform holding pressure through the entire pressure beam is achieved through a linkage mechanism, ensuring synchronized cylinder actuation on both sides. Flexible saw stroke adjustment enables the operator to select the desired stroke either full way or run out panel return depending on the panel length to be cut; this reduces considerable cycle time. Complete with: -- Fence made of cast iron and the surface precision ground is fitted with a flip-over stop for convenient repetitive cutting; saw carriage runs with bronze wheel, which is CNC lathe precision machined or accurate concentrically producing fine smooth surface cut; the guide rods, hard chrome-plated, provides rigid support for saw carriage; the ripping accuracy is guaranteed. -- 1 HP drive, variable speed saw carriage, cuts 16 - 98 FPM; return speed 98 FPM. Includes: -- Dust chute is covered with a split rubber to form a totally enclosed dust collection system, and fully prevents the hose from being broken resulting from its fatigue. -- Sectional dust guard not only acts as a surrounding saw blade guard but also fully prevents sawdust from spraying out of the machine.

CAM-WOOD - VPS Twin, ...Automatic Vertical Panel Saw, for Cutting & Grooving Aluminum Composites (78-3/4" x 157-1/2").The VPS TWIN is engineered with specific features for cutting or grooving Aluminum Composite or similar materials. Top to Bottom cutting height is 2,000 mm (78-3/4"). Saw head w/motor rotates 90° for rip or crosscutting grooving.Automatic Cutting Cycle: Cutting or grooving length "rip cut: Left/right" is 4,000 mm (157-1/2"); cuts or grooves panels up to 20 mm (3/4") in thickness; Digital LED readout scales for both X- & Y-axis measurement. Unique saw head design: (1) Standard Saw blade and (1) V-grooving blade all in (1) housing. An operator can select a standard or V-grooving cut automatically by a flip of a switch. Automatic “Flip of the Switch"; changeover from a cut-to-size blade cutting operation to channel grooving cutting; includes precision depth control required for ACM (Aluminum Composite Material) panel grooving and bending.4.0 HP Motor (5.5 HP Option): Spring-loaded floating shoe guide enhances dust collection and safety by enclosing the blades & cutterhead, automatically shifting material back support grid; shifts away from the saw blade cut line, preventing cuts into the grid support strips, while rip cutting horizontally; grid senses the blade/cutter position and automatically shifts away, built-in Dust Collection with collection bag mounted on the rear of the Saw frame. Alternatively, remove & bypass the bag for easy connection to your existing Dust Collection System.Equipped with: Precision ground bottom edge support rollers to facilitate easy loading & positioning of the larger or heavy panels.Vertical cutting stations are spaced at 40" increments to lock in the Saw beam for vertical crosscuts. Cross- or rip cutting: Material always rests firmly against the "slightly angled" back grid support; repeat rip gauge for duplicating multiple horizontal cuts; a foldout shelf that runs the entire length of the frame for small parts cutting and (2) standard flip-stops for dimension setting.Includes WARRANTY: 12-Month Factory Warranty covering defective parts and workmanship (not including wear parts); 6-Month Factory Warranty on electrical; manuals; (1) 62T x 230 mm dia. Main Saw Blade; (1) 10T x 200 dia. V-grooving blade (90°); 5,800 RPM.

CAM-WOOD - VPS IS Compact, ...Vertical Panel Saw (76" x 122" w/Scoring)Short 10' Frame Compact Model with Scoring offers many features in a compact space-saving design. -- Top to Bottom cutting height is 2,030 mm (78-3/4") without scoring and 1,930 mm (76") with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length "rip cut from left/right" is 3,100 mm (122"); cuts single or stacked panels up to 42 mm (1-5/8") in thickness.Features: -- Separate 5" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine & Hardwood, especially preventing surface chipping when cutting laminated materials. -- Includes: -- 4 HP Motor and true scoring with a 125 mm (5") dia. 24-teeth blade, 250 mm (10") dia. 80-tooth main blade; spring loaded floating saw blade enclosure - shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- Auto-shifting material back support grid shifting away from the saw blade cutline prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away.Equipped with: -- Precision ground bottom edge support rollers to facilitate easy loading & positioning of the larger or heavy panels; both standard inch & metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm (in inch or metric) increments to lock in the saw beam for vertical crosscuts. -- (2) Adjustable flip-stops on inch (metric available) measuring scales, one located on the lower rail and the other on the foldout shelf at the middle of the frame. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down. -- Includes: -- Pneumatic lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade.Optional: -- Add ACCURATE TECHNOLOGY Proscale Digital Readouts on X & Y axis ($ 2,000 upgrade).

CAM-WOOD TX-P3200SAX Sliding Table Panel Saw w/Motorized Raise & Lower.Heavy-duty construction, vibration-free operation. Easy to set up and quickly adjusts. High accuracy, free movement sliding table without wear resistance.Specially designed double rollers carriage made by aluminum profile. Stable, torsion-free cross slides with easy running swinging arm.Features: -- 126" Cutting length w/scoring; 126" x 17" Anodized sliding table that locks in any position for easy loading. -- Motorized Saw blade up or down movement by 1/4 HP electric servo motor; tilting by manual handle wheel. -- Scoring unit for clean, accurate chip-free cutting, ready for edge banding. Specifications: -- 7.5 HP Main saw motor; 45° tilting (30 mm) main saw arbor; 14" Main blade dia.; 3,000/4,000 & 5,600 RPM arbor speed. -- 5.3" Max. material thickness at 90°; 3.1" at 45°. -- 1 HP Scoring saw motor, 5" dia. scoring blade; 8,000 RPM. -- Equipped with: 49" Max. ripping cap.; micro-adjustable rip fence and extendable crosscut fence to 10' with (2) flip stops. -- Articulating overarm protection guard; outboard and rear extension tables. -- Includes: Saw Blade(s), Maintenance Tools, Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD TX-P3200PL Sliding Table Saw w/Motorized Raise/Lower/Tilt & Programmable Rip FenceHeavy-duty construction, vibration-free operation. Easy to set up and quickly adjusts. High accuracy, free movement sliding table without wear resistance.Specially designed double rollers carriage made by aluminum profile. Stable, torsion-free cross slides with easy running swinging arm.Specifications & Features: -- 126" Cutting length w/scoring; 126" x 16" Anodized sliding table that locks in any position for easy loading. -- Saw blade moves up or down, tilting and fence movement driven by 1/4 HP electric servo motor. -- Scoring unit for clean, accurate chip-free cutting, ready for edge banding. Equipped with: -- 9 HP Main saw motor; 45° tilting (34 mm) main saw arbor; 15-3/4" Main blade dia.; 4,000/5,600 RPM; -- 5.3" Max. material thickness at 90°; 3.1" at 45°. -- 1 HP Scoring saw motor, 5" scoring blade; 8,000 RPM. -- 49" Max. ripping cap.; (200) memory program control for the rip fence, saw blade height and tilting angle via touch control screen for convenient operations; -- Extendable crosscut fence to 10' with (2) flip stops. -- Articulating overarm protection guard; outboard and rear extension tables.

CAM-WOOD "PROFORMA" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 404: $ 35,500SERIES 408: $ 37,720SERIES 510: $ 39,940Models Include (Table Sizes): 404 (4' x 4'), 408 (4' x 8'), 510 (5' x 10')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: WEIHONG NK105 G3Spindle: 9.0kW (12 Hp) Air-Cooled Spindle 6,000 - 24,000 RPMBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: Servo-Motor and DriverY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: SERIES 404: Rear Linear (6) Tools ISO30, ER32 - SERIES 408/510: Rear Linear (8) Tools ISO30, ER32Inverter: SCHNEIDER 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERWorking Size:SERIES 404: 51’’ (X) x 51’’ (Y) x 7-3/4’’ (Z)SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 404: 87’’ (X) x 74’’ (Y) x 71’’ (Z)SERIES 408: 87’’ (X) x 122’’ (Y) x 71’’ (Z)SERIES 510: 99’’ (X) x 149’’ (Y) x 71’’ (Z)Max Travel Speed: 2350 IPMMax Working Speed: 1100 IPMMachine Net Weight: SERIES 404: 3,520 lbs / SERIES 408: 3,960 lbs / SERIES 510: 4,480 lbsFeatures Include: -- Automatic (12) Tools Linear Type Auto Tool Changer Under the Bridge for Increased Productivity. -- All “Servo Motor"; Driving System: All Axes are Driven by Brush-less Type, High Torque AC Servo Motors. -- DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats Along with On-Board Conversational Applications. -- Optional CAD/CAM System can Create and Edit Part Programs Then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified, and Edited from Here to Create a G-Code. -- DNC is No Longer Required as the PC Directly Stores all Part Programs in a Text Editable File. -- Machine Designed Ready for 3-D Cutting Usage and Superior Performance. -- Moving Gantry Construction for Space Saving. -- The Rigid Steel Frame Construction has been Stress-Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. -- Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. -- Linear Guides and Sliding Blocks are Pre-loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse and Precision. --Th

CAM-WOOD "EXCEL" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 408: $ 91,900SERIES 510: $ 96,900SERIES 512: $ 99,300Models Include (Table Sizes): 408 (4' x 8'), 510 (5' x 10'), 510 (5' x 12')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemAuto-Loading: Auto In-feed Loading Scissor Lift & Out-feed Conveyor TableSpindle: 9.0kW (12.8Hp) HSD Air-Cooled Spindle - 6,000-24,000 rpmBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: Servo-Motor and DriverY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: Rotary (12) Tools ISO30, ER32Inverter: 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionalDrill Bank: Includes (9) Tools HSDCAD/CAM Software: OptionalWorking Size:SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)SERIES 512: 63’’ (X) x 150’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408: 98’’ (X) x 433’’ (Y) x 71’’ (Z)SERIES 510: 110’’ (X) x 531’’ (Y) x 71’’ (Z)SERIES 512: 112’’ (X) x 603’’ (Y) x 71’’ (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408: 8,810 lbs / SERIES 510: 9,970 lbs / SERIES 512: 10,750 lbsFeatures Include: --Nesting Work for Automatic In-feed Loading w/Scissor Lift and Out-feed Unloading w/Conveyor Process. --Automatic (12) Tool Rotary Type Auto-Tool Changer for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by Brush-less Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --DNC is no longer required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress Relieved Prior to Finished Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse a

CAM-WOOD "DYNAMIC" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 408: $ 60,090SERIES 510: $ 63,800SERIES 512: $ 65,080Models Include (Table Sizes): 408 (4' x 8'), 510 (5' x 10'), 510 (5' x 12')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemSpindle: 9.0kW (12.8Hp) HSD Air-Cooled Spindle - 6,000 - 24,000 rpmBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: YASKAWA Servo Drive and MotorY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: Rotary (12) Tools ISO30, ER32Inverter: 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionalDrill Bank: Includes (9) Tools HSDCAD/CAM Software: OptionalWorking Size:SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)SERIES 512: 63’’ (X) x 150’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408: 87’’ (X) x 122’’ (Y) x 71’’ (Z)SERIES 510: 99’’ (X) x 149’’ (Y) x 71’’ (Z)SERIES 512: 99’’ (X) x 173’’ (Y) x 71’’ (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408: 3,960 lbs / SERIES 510: 4,480 lbs / SERIES 512: 4,970 lbsFeatures Include: --Automatic (12) Tool Rotary Type Auto-Tool Changer for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by Brush-Less Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --Optional CAD/CAM System can Create and Edit Part Programs then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified and Edited from here to Create a G-Code. --DNC is no Longer Required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress-Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Trav

CAM-WOOD SM-732 HS 7-Heads High-Speed Trough Feed Moulder(7) Heads (B-R-L-T-T- T-B), working cap. 111 13/16" x 6-1/4"".Specifications: -- Max/Min working width 11 13/16" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 20 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP, top 15 HP and bottom 15 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,000 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- PNEUMATIC LOAD INFEED SIDE PRESSUREWhile high speed feeding, the side pressure on infeed table ensures every timber close to the fence even under different width. It's convenient to adjust quickly. --OVER HEiGHT PROTECTIONIn case workpiece exceeds the rated maximum height, it will be restricted by the over height protection device provided at the workpiece infeed end. -- HYDRAULIC OUT-BOARD BEARING SUPPORT TOP AND BOTTOM SPINDLESpecially designed hydraulic supports on the top and bottom spindles assure maximum stability while performing high speed and heavy duty machining. -- PNEUMATIC LOAD SIDE PRESSURE WHEELS The front side air pressure wheel on left vertical spindle fully eliminates problem when feeding short or narrow stock not smoothly. The pressure plate is easy and quickly to adjust. -- PNEUMATIC LOAD TOP PRESSURE PLATEThe front pressure plate for top spindle is available to apply an air loading device ensuring maximum stability while performing high speed cutting -- CENTERAL LUBRICATION POINTThe lubrication point are located at the centralized plate for convenience. -- POWERED INFEED TABLE ROLLER The roller in the infeed table is powered, providing a smooth feeding effect for feed stock. -- VERTICAL SPINDLE AXIAL ADJUSTMENT UP TO 60MMIt allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. The 60mm spindle adjustment provides full utilization for a single cutter. -- CENTRALIZED PRESSURE ADJUSTMENT• All pressure regulations for the entire pneumatic system are centralized at the front of the machine for added convenience in pressure adjustment, and sectional pressure adjustments for all pressure rollers ensure consistent pressure.• Clear numerical indicators are provided to correspond directly to the pneumatic mechanisms on the machine, allowing operators to make adjustments based on different processing requirementsAvailable options: -- Automatic Jointer for all (6) heads add: ...$45,600 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control sys

CAM-WOOD BR-OO42BX DOUBLE ROW LINE BORERHeavy Double Head Line Borer with (2) 21-spindle heads; 32 mm spindle spacing.Specifications: -- Drilling from the bottom up and with 5-1/2" - 23-1/2" distance between rows. -- Drilling vertically from the bottom allows the chips to drop down falling out of the holes. -- Drilling depth of up to 3" max., takes only seconds to set. -- (2) 2 HP - 3,400 RPM motors; spindles with steel gears & high quality bearings. -- Easy repetition by (2) air index pins for continuous line drilling, left and right roller track supports extend up to 400 mm (15-3/4") for larger panels.Features and Includes: -- 120" Back fence with (4) repeat "flip" stops; includes 27-3/4" (704 mm) fence for quick positioning of flip stops. -- (6) Pneumatic holddowns to automatically actuate when the drill cycle begins. -- (42) "Quick Change" chucks for easy tool change. -- Magnetic motor controls and 1/4" air regulator with filter and oiler; 100 PSI required air pressure.

CAM-WOOD BR-2132 Boring Machine21-Spindle boring head on 32 mm centers with position indicator.Features & Specifications: -- Stops in 0° & 90° with pneumatically assisted positioning in vertical & horizontal. -- 0" - 3" Adjustable drilling depth with speed control. -- Head height fine adjustment with mechanical digital readout. -- 2 HP - 3,400 RPM Motor. -- Cast iron 37-1/2" x 19-1/4" table with side fences for mirror-image. -- Line boring fence with repeat stops. -- Foot actuated pneumatic clamps & drill cycle.Complete with: Magnetic starter, overload protection. -- Optional: Quick-change chucks $28.00 ea.

CAM-WOOD WS-M1000 NAX Planer Sander -- 2 Heads with 39.4" width capacity planer head and combination sanding headFeatures: -- This machine is especially designed for tale off heavy materials such as glue panel, bend board, rough lumber. -- The first head is a knife planer head, with 25 HP motor. The spiral planer cutterhead is fitted with 14 x 14 mm, four edge throw away Tungsten Carbide knife inserts, providing superior chip removal rate, minimum noise, and extremely smooth cutting effect. Changing knife inserts are conveniently done without removing the cutterhead. -- The second head is a combination of drum and platen driven by a 20 HP motor, belt size 40.5" x 78 3/4". (1030mm X 2000 mm) -- Anti-kickback fingers, mounted at the infeed of the machine, this anti-kickback finger gives a safety guard for the operator. -- Insufficient pressure protection, in case insufficient working air pressure occurs, the machine brakes automatically for safety guard.Irreversible running of pressure roller, runs a single direction only, giving an additional safety guard for panel kickback. -- Motorized elevation of conveyor table (micro-computer controlled with digital readout), it accurately displays the position of the conveyor table and automatically moves to the setting thickness for planning, sanding. -- Panel cleaning brush roller; built at outfeed end of the machine, this cleaning brush roller cleans the powder on the sanded panel. -- Hold-down plate is hard chrome treated for maximum wear resistance.Technical Specification: -- Working width 39.4" (1000 mm). -- Working thickness up to 6 1/4". -- Minimum working length 21". -- Feed speed 10 to 90 FPM inverted driven by 3 HP motor. -- Table raised and lowered by 1/2 HP motor. -- Cleaning brush driven by 1/2 HP

CAM-WOOD WS-MN700NAX Planer/Sander Equipped with: -- (2) Heads with 27" width capacity planer head and combination sanding head -- This machine is specially designed for take-off heavy materials such as glued-up panels, bend boards, and rough lumber. -- The first head is a knife planer head, with 20 HP motor. The spiral planer cutterhead is fitted with 14 x 14 MM, four edge throw away Tungsten Carbide knife inserts, providing superior chip removal rate, minimum noise, and extremely smooth cutting effect. Changing knife inserts are conveniently done without removing the cutterhead. -- The second head is a combination of drum and platen driven by a 20 HP motor, belt size 28 3/4" X 75" -- Anti-kickback fingers, mounted at the infeed of the machine, these anti-kickback fingers provide a safety guard for the operator.Features: -- Insufficient pressure protection, in case insufficient working air pressure occurs, the machine brakes automatically for safety guard.Irreversible running of pressure roller, runs a single direction only, giving an additional safety guard for panel kickback. -- Motorized elevation of conveyor table (micro-computer controlled with digital readout), it accurately displays the position of the conveyor table and automatically moves to the setting thickness for planning, sanding. -- Panel cleaning brush roller; built-in at the outfeed end of the machine, the cleaning brush roller cleans the fine sanding dust off the sanded panel. -- Hold-down plate is hard chrome treated for maximum wear resistance.Technical Specification: -- Working width 27" -- Working thickness up to 6 1/4" -- Minimum working length 20" -- Feed speed 20 to 90 FPM inverted driven by 3 HP motor -- Table raised and lowered by 1/2 HP motor -- Cleaning brush driven by 1/2 HP

CAM-WOOD BR-50 Universal Boring MachineFeatures & Specifications: -- 3 HP Pneumatic Universal Boring Machine, all adjustments feature an index plate for accurate and convenient reading, workplace clamping. -- Vertical Base travel, 24". Horizontal Base travel 12". -- 0" - 4" Spindle stroke, 7/16" - 14-thread screw shank, 1/2" max. bit capacity. -- Table Size: 15" x 22". -- Complete with: Air operated overhead holddown clamp and foot pedal operated drill cycle. -- Drill Head can be swiveled 360° and Optional Multi-Spindle drill heads available.

CAM-WOOD BR 25 Horizontal DrillFeatures & Specifications: -- Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back. -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic holddown clamp for up to 3" thickness. -- 12" x 10" Table size. -- 1/2" Drill chuck / 3/4" max. bit diameter.

CAM-WOOD BR 25 + 1 Horizontal and Vertical DrillFeatures & Specifications: The model BR-25+ 1 has the same features as the BR-25, except it's fitted with an additionaluniversal boring head, making it ideal for drilling holes on K/D furniture. -- The boring head can be swiveled 360 degrees for angular drilling, as desired -- Vercical Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back., spindle node threaded 7/16-14" -- Horizontal spindle 2 HP, 3450 RPM-3 phases motor, adjustable 360 degree, spindle nose threaded 7/16-14" -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic holddown clamp for up to 3" thickness. -- 12" x 10" Table size.
