CAM-WOOD RD-5412-SC Tenoner with Dowel DrillTenoning/Coping machine for straight or miter material. Great machine for miter door production or stile and rail stock. Equipped with: -- 6" High stackable spindle by pneumatic up & down with (3) different stops; easily and accurately setup for each cutter position. -- Drill heads for dowel hole at each end. -- One shaper head at each side of the table. -- Table moves from right to left by variable speed Pneumatic-Hydraulic power to achieve the fully cutting power. -- Twin table moves in and out separated for tongue and groove, end match application. -- Twin heavy-duty pneumatic pistons hold down the workpieces tightly to the table during the cutting process.Features: -- Rigid construction on the heavy sheet metal frame, cast iron table & base for durability usage. -- Heavy-duty industrial motor is suitable for heavy duty cutting under full load. -- Linear guide rails and bearings let the operator moving the table smoothly. -- Cast iron fence locks in the table groove to finish 45° cut easily. -- Automatic cycle function, just place the material against the stops, the machine will automatically clamp, move in for shaping/tenoning, come out and release the hold down.

CAM-WOOD 0400-SCX 40" AUTOMATIC COPY SHAPER Specifications: -- 3" to 40" shaping capacity; 15" x 35" rectangular capacity; table diameter is 27"; -- 1.5 to 6 RPM table speed; cutterhead speed is 9,000 RPM powered with a 7-1/2 HP motor; 1" dia. x 5-1/2" long spindle accepts up to 6" dia. cutterheads. -- 2" dia. follower wheel and 2 HP feed motor -- All controls are located on the control panel for easier touch up to operation. -- Equipped with PC program control for easy maintenance and durability usage. -- Easy set up at any position, variable speed table makes it possible for the machine to be operated at any cutting speed. -- The variable feed rate can be adjusted to give optimum output according to stock thickness and component shape. -- Unique design of table runs clockwise and counter-clockwise to help eliminate tearout while cutting with or against the direction of grain. -- Advanced timer control of overlap table rotation to eliminate cutter joint mark. -- Cutter head feed is controlled by pneumatic-hydraulic system to smoothly apply even pressure for fast and smooth cutterhead feed. -- Heavy duty motor for maximum cutting capacity. -- Precision sealed long life, high speed bearing for durability usage. -- Heavy sheet metal frame and cast iron table. -- Cutter head feed designed to automatically slow down when approaching to the work piece, assures no bumping to eliminate cutter marks left at the starting point for an exceptionally smooth finish. -- Those models are designed for medium size shaping & profiling. Easy & convenient to operate. -- SETUP KIT, INCLUDES CUTTER & TEMPLATE, ADD $1,098

CANTEK - SS512TB Tilting Spindle ShaperSpecifications: --Tilting spindle from -5° to +45° and 6" x 43" fence. --1-1/4" interchangeable spindle is standard (other sizes available). -- Large cast-iron table is ground and polished for maximum stability and durability. -- Powerful 7.5 HP motor for even the most demanding profiling work. -- Five spindle speeds can be easily adjusted to suit your tool diameter. -- 5-1/2" Useable spindle length, above table 13-¼"; below table 8-¼". -- Electronic spindle brake for added safety and facilitates fast changeover. -- Precision fence assembly with micro-infeed and outfeed fence adjustment. -- The finger-style fence allows the fence to be adjusted around the cutter for added safety and workpiece stability. -- Table size 31 ½"; x 39.4″. -- Dust port (1) 5″ on guard, (1) 4" into the table.

CANTEK SS512CSB Heavy Duty Production Shaper with Sliding Table & Spindle Brake7.5 HP Features: -- Cast iron sliding table runs on ball bearing for smooth table transition. -- Cast iron ground & polished table with insert rings; table size: 31- ½"; x 39.4″. -- Precision ground and electronically balanced spindle. -- V-belt drive with (5) feed speeds is easily accessed from the front of the machine. -- Electric spindle brake for added safety. -- Spindle lock - with limit switch safety, machine will not start with lock engage. -- Micro spindle height adjustment with dial indicator. -- Interchangeable cutter spindle. -- Forward/reverse spindle rotation. -- Adjustable "finger" type fence Independent micro-fence adjustment on both sides. -- Includes the following standard equipment: 1- 1/4" Spindle, (1) 5"; dust chute on guard & (1) 4"; dust chute in the table, safety guard, Miter tenon jig, and Telemecanique magnetic controls.Net weight 1034 Lbs. Machine dimensions 48.4"; x 39.4"; x 52 ¾";. Shipping weight 1166 Lbs.Shipping dimensions 45 ¼"; x 37"; x 41";

CANTEK SS-512TSB Tilting Spindle and Sliding Table Shaper:7.5 HP - 3-Phase motor, overall table dimensions 31.50" x 39.40", sliding table 10.25" x 39.40". -- Spindle stroke 7"; 1-1/4" dia. spindle with 5 MT receiver and 4-3/4" cap. under the nut. Spindle tilts -5° & +45°. -- (5) Spindle speeds: 3,000, 4,000, 6,000, 8,000 & 10,000 RPM.Complete with: Spindle reversing switch, micro-adjustable fence 6" x 43", thermal overload protection and dust hood.16 weeks delivery.

--In Auction: https://exfactoryauctions.com/Detail/SA-231009/event/A122024$1 --No RESERVE!-- CHIA LUNG KR-30 2-Spindle Dual Table Automatic Rotary Copy Shaper Equipped with: (2) 19” Dia. x 35-1/2” H Tables. (2) 6-1/4” Dia. Center clamp plates.

CIRCLE T LM116 Easy Lock Miter Joint MachineSpecifications: -- Material thickness 1/2" - 1″. -- Min. material width: 1-1/4″ & 2" (2-Sided). -- Min. material length 12″. -- Finish angles 30 - 90°. -- Spindle dia. 1-1/4″. -- Spindle speed 8,200 RPM.Equipped with: -- 5 HP Spindle motor. -- 1/2 HP Feed motor. Complete with: -- 11-Roll Variable Speed Positive Grip Feeder.

COMEC - FAS/2, ...Corner Milling MachineCOMEC FAS is a dedicated milling machine with: Inclinable heads for machining the corner of chair seats. Specifications: -- (2) Heads with: 5.5 HP motor and 40 mm spindle shaft. -- Max. cutter size: 150 mm (5.9"). -- Tilting of milling units: 20°/ +45° in horizontal plane. -- Fixed left hand column to support head unit. -- Max. working height: 200 mm (7.8").

Extrema WS-110 Single Spindle Shaper -- 3/4" & 1" Interchangeable spindles. -- 3 HP Single Phase, 3,450 RPM motor designed for operation in most smaller shops -- Belt drive for spindle speeds of 8,000 & 10,000 RPM _ 2-5/8" capacity under the nut (3/4" spindle) and 3-7/8" vertical spindle travel will accommodate a variety of cutters. -- Large Table size 28" x 30" with a 6" max. dia. table opening -- Includes Fence assembly, miter gauge, 1/2" collet adapter, and power feeder.

FELDER FORMAT4 PROFIL 45, ...2" 12 HP Interchangeable Tilting Spindle Sliding Table Shaper, with Power FeederAllows Operator to store up to (99) programs of spindle heights & angles.Specifications: -- 12 HP Motor operates on 230 Volt / 3-Phase power. -- Motorized rise & tilt of spindle: Tilts back 45° & forward 5°. -- Motorized fence w/digital readout. -- Sliding Table with clamp. -- STEFF 3-Wheel Power Feeder w/WESTERN ROLLER soft wheels. -- AIGNER Integral fence and AIGNER CENTREX guard. -- Articulated arm to move Power Feed out of the way for large curved work. -- The fence is hinged, so it can be folded below the table, out of the way for doing large pattern work, as well.NOTE: Spindle does not currently function.

FLETCHER EZ-DOOR Raised Panel Door MachineThis freestanding machine can produce an entire 5-piece door in a matter of minutes. Easy to operate, the E-Z Door has a 4-position configuration to produce raised panels, cope/stile profiles and mullions for glass doors. Cathedral doors are produced by using a quick change template system.Specifications: -- Select cutter and material stop with the press of one button. -- Simple four position one spindle design. -- PLC controlled pneumatics. -- Rigid lubricated spindle assembly. -- Re-circulating ball bearing slides. -- 10 HP 230 or 460V/60HZ spindle motor – (460V/3PH=17FLA) – (230V/3PH=33FLA) -- 6,500 RPM spindle speed. -- 62 inch travel length standard with circulating ball bearing slides, cut rails to 59"; and panels to 55"; -- Includes: (4) Standard cutters (shape to be decided), others optional. -- Includes: one template of customers choice. -- 1-¼"; Arbor. -- CFM requirement is 392.Made in North Carolina, USA!

Gomad "DFDA-455" Sliding Table Single Spindle Shaper -- Specifications: 2-1/64" (55 mm) spindle currently, 7.5 HP belt drive motor, (4) speeds 4,000/6,000/8,000 & 10,000 RPM, 3-9/16" spindle travel, 3/4" up to 2-11/64" dia. interchangeable spindle, reversing spindle rotation; heavy duty 36" x 40" cast iron table, (3) pneumatic clamps, double end fence, 4.5" dia. dust chute. -- Complete with: 13" wide sliding table, (4) Hold down springs, mounting collars & bolts, miter gauge with stop rod, and foot brake, capable of doing arch molding work.NOTE: Don't go too much by the appearance. In running condition before disconnect in 2013, currently stored in the facility's basement.

GRIGGIO T-100 SHAPERSpecifications -- 6.6 HP Motor. -- 1-1/4" dia. spindle, " spindle system. -- (4) spindle speeds of 3,200 - 4,200 - 6,200 & 8,000 RPM -- 5-1/2" under nut, hand wheel for vertical positioning. -- Fence with micrometric adjustment on 39.3" x 25.2" table.Complete with: Automatic spindle brake, motor reversing switch, shaving hood, and safety switch on shaper door.Includes: 3-Roll powerfeederNOTE: The above specifications are taken from the Seller and literature and are considered accurate. As always, please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

GRIZZLY G9968 1-1/4" 7-1/2 HP Spindle Shaper, with Power FeederSpecifications: -- Table size 33-1/4" x 91-3/4" x 33" H. -- Table insert dia. 4, 8, &13". -- Spindle length 6". -- Max. cap. under nut 5-1/2". -- Max. cutter dia. 8-1/2". -- Spindle stroke 5". -- Spindle speeds 5,500, 7,500, & 10,000 RPM.Equipped with: -- 7-1/2 HP - 3,450 RPM Motor, with Brake. -- Forward & Reverse spindle rotation. -- Spindle lock. -- 45-1/4" L x 5-1/8" H Cast-iron fence. -- Front table pullout extensions.Complete with: -- 2003 GRIZZLY "G7873" 1 HP 4-Speed 3-Roll Power Feeder, 220 V/60 Cy/3 Ph., with Speeds 13, 26, 33, & 66 FPM.Shaper Dimensions: 92" x 40" x 45" H.Shaper Height with Feeder: 60"Shaper Weight: 1,540 Lbs.Feeder Weight: 144 Lbs.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i62 GRIZZLY G7214Z Shaper Specifications: 1-1/4" Dia. interchangeable spindle, 7.5 HP - 3,450 RPM motor; 3,600, 5,100, 8,000 & 10,000 RPM spindle speeds via 4-step V-pulley. 5-1/8" Cap. under nut when using the 1-1/4" spindle, 3-1/4" spindle travel, 34-3/4" x 35-1/2" cast iron table, 43" working height. Table Counterbore: 7" dia. x 5/8" deep Complete with: Adjustable Fence with integrated 4" dust collection shroud, reversing switch & magnetic controls, 3-roll power feeder

GRIZZLY - G1026, ...Single Speed Shaper w/Feeder & Mobile Base3 HP - 3,450 RPM Motor; 1/2", 3/4" & 1" dia. interchangeable spindles; 2-1/2" spindle cap. under the nut and with 3" spindle travel. -- (2) Spindle speeds of 7,000 or 10,000 RPM; reversing spindle switch. -- Features: 28-1/4" x 21-3/4" table; 34" table height.Complete with: Magnetic spindle brake, adjustable fence & 3" dia. dust extraction outlet.3-Roll 4-Speed Power Feeder & Mobile Base!

HOLYTEK SS-512 TS Shaper with Tilting Spindle, and Power FeederSpecifications: -- 1-1/4" Interchangeable spindle, 7.5 HP motor with (5) spindle speed settings of 3,000 - 4,000 - 6,000 - 8,000, & 10,000 RPM. -- Approx. 6" max. cap. under nut, 31" x 39" cast iron table. -- Insert ring diameters 2.8", 4/3", 6" and 8". -- Tilting spindle +10° and -45° -- Vertical movement of the spindle 7" -- sliding tableComplete with: -- Reverse rotation switch, adjustable fence assembly, and dust hood. -- 3-Roll Power Feeder

JENKINS - JSM, NC Controlled Shaper & MortiserNC Controlled with: (1) Shaper head with ATC (18) tools, (1) tenon head, and (1) mortising head.Machine Specifications: -- Total X-travel: 122". -- Y-Axis (useful zone-1 only): 8". -- Min. length rail: 4". -- Max. length rail (Zone 2, 3 only): 96". -- Min. width rail: 1-1/4". -- Max. width rail: 12". -- Min. stock thickness: 1/2". -- Max. stock thickness: 2-1/4". -- Max. arch height (Zone 1 only): 6".Spindles: -- (1) 10 HP - 12,000 RPM non-tilting Cope spindle. -- (1) 10 HP - 18,000 RPM non-tilting high-speed Tenon spindle. -- (1) 5 HP - 18,000 RPM non-tilting, high-speed Mortise spindle. -- Tool Changer Capacity: (18) Tools.Controls: -- Industrial PC: Base powered by NEXCOM PEAK "760VL2" all-in-one computer card, industrial-grade computer chassis, LCD color touchscreen. -- YASKAWA Model "V1000": Adjustable AC frequency drives. -- ALLEN-BRADLEY: AC Servo Plus drive model "Ultra 3000".Over all dimensions: -- 16-1/2' Length. -- 120" Width. -- Floor-to-top guarding: 55". -- Floor to tabletop: 37-1/2".

The Model 390 Automatic Shaper is a New concept in shapers. -- This "New Shaper" is conveyor fed, making it ideal for shaping small parts which could not be fed with a conventional Power Feeder. -- The 7.5 HP inverter controlled variable speed shaper can shape pre-arched panels automatically. Using a Template, it can also hog out arched panels. -- Horizontal and Vertical shaper adjustments with digital position indicators and the 5-position fence make profile changeovers extremely quick and simple. -- Standard stack tooling spindle -- Optional upgrade to 460 V, additional $ 250.

LARICK 410 Shaper / Sander (Feed Through)Designed and Manufactured to give years of dependable service.Features: -- The 410 will Shape and Sand a wide variety of workpieces. -- The 410 is Standard with a New easy-to-use Touchscreen that displays RPM and Load for each motor. -- With a 6" Wide Feed Chain and (4) four staggered rows of hold-down wheels.Specifications: -- 7.5 HP inverter controlled variable speed Shaper. -- Two 2 HP Sanding heads with 1" Counter-rotating spindles. -- Each station tilts forward 60° and Backward 40° and will accommodate up to 9" dia. sanding wheels. -- 0.75 HP motor on the Feed Chain. -- All have Digital readouts for speed and Load. -- Horizontal and Vertical shaper adjustments with digital position indicators and the 5-position fence make profile changeovers extremely quick and simple. -- Please call for pricing on the 410-FLT (floating heads).
