Equipment For Sale

CAM-WOOD TRS-805-H2X Multiple Round Pole MakerFeatures: Single to Multiple Round Pole Making with Flutes all in one passSpecification: -- Working Capacity (Maximum Working Size): 8"; Width, 4-¾";He right. -- Pole Making Length: Minimum10";, Maximum Unlimited. -- Spindle : Precision spindles are manufactured of SCM-4 tool steel (imported from MISHIBISHI Japan), heattreated to HR 46° (ROCKWELL CScale) and the 6,200 RPM spindle are fitted with class 6SKF match ball bearings per spindle then mated to precision machined spindle housings. -- Besides, the spindle body and whole bearing house (include the appearance and interior of the bearing house) has been completely burnished.So, the high hardness material, and high-class SKF ball bearings, and precise spindle-body and bearing house, finally by SHEN KO accurate combination technique. -- The spindle must meet every user’s requirements. -- Spindle tolerance is guaranteed included to (0.002mm / 0.00007") accuracy.Transmission (Drive) Belt: All spindles running are powered by V-shape- double belts (MITSUBISHI) without slipping problem Cutters: Arbor Size 40 mm • Cutting Cycle: 1stTop - 4";to 6-1/4"; Dia., 2nd Bottom - 4"; to 6-1/4"; Dia.Cutting Spindle Motor; 1stTop10 HP, 2nd Bottom 10 HP, Cutter Speed:6,200 RPM Equipped With And Features -- Top head and pressure roller power up & down by 1 HP motor -- Operating panel separate from control cabinet, easy to operate. -- Mechanical digital read-out. -- Mobile jog panel box for setting up. -- Central lubricating for spindles. -- Manual oil pump to remove the resin from table. -- Each table has (2) holes for lubrication.Include - ( 1 ) One size / set of the Cutters, Jig, -- Hold-Down Plate, -- Fence, spacer) -- Optional Round Pole Cutters $2,269.00 each size per set

CAM-WOOD RS-DW2400X 8' Overhead Rail Saw w/ Bevel CuttingFeatures: -- Programmable cutting cycle for higher production output -- 45 to 90 degrees tilting angle cutting. -- Variable Cutting Speed by Inverter. -- Rail is treated hardened, precision ground for maximum wear resistance and slide accuracy. -- Saw head runs on ball bearings giving effortless and smooth movement -- One piece casting iron arm for durability usage — heavy sheet metal stand. -- Quick tilting positions stop at right-hand 45º -- The Saw head is firmly set at any angle desired. -- Safety saw blade guard. -- Anti-kickback attachment included. -- Full-power industrial motor for durability usage. -- Overload protection switch.Available in sizes from 4' to 14' width capacitySpecifications: -- 8' Max cutting length -- 5-1/8" Max cutting thickness -- Saw blade speed 2.900 RPM -- No. of Head Travel Bearings, 8 -- Spindle dia. 1" -- Motor; 7.5 HP, 3 Ph, 230 V -- Hold down cylinders ( psc ) 3, Front & 3 Rear -- Width od table 50" -- Head Swiveling ( Horz ) 45 - 90 degreeOptional: Three of the Roller Tables; $599.00, each 4 ft Length

CAM-WOOD Continuous in-line Long Board Vertical Finger Joint System, Model "UCT-210"Up to 210 mm (8") Wide x 75 mm (2.95") Thick x Unlimited Assembled Length System Specifications: -- Incoming board lengths from 39"; to 118" (1,000 mm - 3,0000 mm). -- Board widths from 1.96"; to 8.26"; (50 mm - 210 mm). -- Board thickness from 1" to 2.95"; (25 mm - 75 MM). -- Board out-feed length unlimited (Conveyor to be quoted separately) -- Glue type to be used: PVAC. with Standard pneumatic pump and spreader included ( For different glue then PVAC Glue pump and applicator not included) -- Board species: SOFTWOOD and HARDWOOD. -- Board moisture content: 8% to 12%. -- Infeed board qualities: Lumber runs best on Finger Jointers when surfaced on (4) sides (S4S) (Tolerance +/- .2 mm (.008"). System prefers straight boards with 90-degree corners. UCT-210 Mechanical Specifications: -- Top infeed feed rolls powered with (1) 2 HP motors. -- Bottom infeed feed rolls powered with (1) 2 HP motors. -- In-feed Inverter with (1) 5 HP motors. -- Top Shaper Spindle powered with a 30 HP motor. -- Maximum Cutterhead length, 8.2“(210 mm). -- Maximum Cutterhead diameter, 7"“(180 mm). -- Typical cutter pitch, 4.0 mm. Length, 10 mm - 12 mm (Other sizes available). -- Shaper spindle moving power by 2.6 HP Servo Motor. -- In-feed speed from 32 to 195 FPM (10 ~60 m/Min). -- Outfeed cut-off saw motor, 5 HP. -- Cut-off sawblade, 14“ dia x 120 teeth (included). -- Cut-off sawblade speed, 2,850 RPM. -- Hydraulic pump power, 30 HP. -- Top outfeed feed rolls powered with (1) 2 HP motors. -- Lower outfeed feed rolls powered with (1) 2HP motors. -- Out-feed Inverter with (1) 5 HP motors. -- Glue injection Glue Applicator for Standard PVAC glue. Infeed/Outfeed options: -- Infeed power roller conveyor 6000mm (236") long Additional: $ 8390 -- Outfeed powered roller conveyor 15,000 mm (48') long Additional $ 43,890Optional Automatic 20 ft Cross InfeedPower Conveyor System Working size L = 1000 MM ~ 6000 MM, W= 50 ~ 305 MM, T=25 ~ 110 MM ( Lenght 39" - 236" X Width 2" -12", Thickness: 1" to 43.3")Infeed roller Conveyor 3 HP1Cross feeding system 3 HP1Feeding speed of 15 M/min (48'/min.)Storage area width 2500 mmAdditional cost: $61,990 -- Outfeed roller conveyor 20'' X 8' long Additional: $ 4,890 per sectionNot included with the machine: -- Cutter heads for finger jointer (we can provide quote) -- Gluing system with pump and nozzle if different then PVAC glueGlue pump Option: -- Graco 1K PUR Glue System Additional cost: $ 48,990NOTE: Training, installation & tooling not included TO BE PROVIDED LOCALLY -- Electric power supply to Motor Control Center -- Constant voltage (voltage deviations max.: 5%) -- Temperature range for computer control should not exceed 95°F. -- 65% Maximum relative air humidity for computer control system --Dust exhaust system: (V=30M/S at a low pressure of 12M BAR) --Compressed air connection to machinery: 7~8 KG/cm² – 8 BAR --Electrical c

Cam-Wood TRS-MR-1300 X 75mm Roll Feed Gang Rip SawSpecifications -- Working thickness: 10 - 100mm • -- Working width: 530 - 1300 mm • -- Working thickness : 10 – 75 mm / 100 mm • -- Saw Blade 14", • Washer Diameter 110mm • -- Minimum length of work piece when feeding consecutively: 600mm • -- Number of spindle : 1 • Equipped with & Features -- Up & down motor : 1 HP x 1 • -- Feed speed : 6 - 15 M/ min. • -- Feed motor: 7.5 HP x 1 with Inverter • -- Multiple rip saw spindle motor:150 HP / 200 HP • -- Spindle diameter : 80 mm with two key-ways 10 mm5 mm • -- Spindle R.P.M.: 4,000 R.P.M. • -- Movable 1300 mm Saw Shaft Support for easy saw blade replacement.

Cam-Wood TRS-MR-1300 X 100mm Roll Feed Gang Rip SawSpecifications -- Working thickness: 10 - 100mm • -- Working width: 530 - 1300 mm • -- Working thickness : 10 – 75 mm / 100 mm • -- Saw Blade 14", • Washer Diameter 110mm • -- Minimum length of work piece when feeding consecutively: 600mm • -- Number of spindle : 1 • Equipped with & Features -- Up & down motor : 1 HP x 1 • -- Feed speed : 6 - 15 M/ min. • -- Feed motor: 7.5 HP x 1 with Inverter • -- Multiple rip saw spindle motor:150 HP / 200 HP • -- Spindle diameter : 80 mm with two key-ways 10 mm5 mm • -- Spindle R.P.M.: 4,000 R.P.M. • -- Movable 1300 mm Saw Shaft Support for easy saw blade replacement.

CAM-WOOD INFEED AND OUTFEED PLANER TRANSFER LINE: 20"; Wide X 20’ Long Roller Conveyors with 6,000 lbs capacity and Consisting of the following: NON POWERED IDLE INFEED RIGHT ANGLE ROLLER TRANSFER CONVEYORS -- (4) Conveyor Sections, each 14"; Wide X 8’ Long (SEE DRAWING). -- 2-11/64"; Roller Diameter -- Rolls on 3"; Centers to Handle 2"; x 4"; and Wider -- Supports up to 6,000 lbsPOWERED INFEED CANTED ROLLER CONVEYOR -- With VFD Drive with speed feed 18' to 70 FPM -- 22"; Wide X 20’ Long -- Heavy Duty 3-11/32"; Roll Diameter -- (9) Rolls on 36"; Centers -- (5) Pneumatic jumped transfer roll -- Back Side Adjustable FencePOWERED OUTFEED STRAIGHT ROLLER CONVEYOR -- With VFD Drive with speed feed 18' to 70 FPM -- 22"; Wide X 20’ Long (Longer with Owner Provided Outboard Roller) -- Heavy Duty 3-11/32"; Roll Diameter -- Rolls on 36"; Centers -- Includes (4) Sections of Pneumatically Jumped Skate Rolls -- Heavy Duty Type, Sections are 6"; Wide X 20"; Long NON POWERED IDLE OUTFEED RIGHT ANGLE TRANSFER ROLLER CONVEYORS (SEE DRAWING) -- (4) Conveyor Sections, each 14"; Wide X 8’ Long. -- 2-11/64"; Roller Diameter. -- Rolls on 3"; Centers to Handle 2"; x 4"; and Wider -- Supports up to 6,000 Lbs.

CAM-WOOD XCL-59 Auto Copy Lathe. via a template. SPECIFICATIONS: --Max. Between Center: 59". --Max. Finish Product Dia: 4-1/4". --Spindle Speed: 2,000 ~ 6,000 RPM. --Main Motor: 7.5 HP. --Hydraulic Motor: 3 HP. --Template Copier: One. --Model Copier: One. --Max. Copier Travel: 3-1/8". --Total Cutting Knives: 4 (including top plunging knives) --Feed Speed: Variable. --Includes (2) top plunging knives which can hold profiled or flat knives for dowel ends, etc. --Operation Modes: Manual Semi-auto, Auto. --Gross Weight: 3,400 Lbs, Net Weight: 2,900 Lbs.FEATURES: • Suitable for small quantity and multiple style production uses.• Can use sample or template for duplicate productions.• Cutter carriage forward and backward movements are hydraulically operated with feed.speed control, providing a smooth motion and stable cutting performance.• Adopts the precision hydraulic copy unit, most forms can be duplicated.• Easy to operate and lower maintenance costs.• There is a tongue shaving knife to pre-cut and guide ring to support the workpiece whencutting. This enables the cutting performance to be stable and more accurate.• Equipped with two sets of copying devices; one is copying device, which is driven by links andadopts U-Cutting tools. The other one is sample copy device by hydraulic system and adopts V-Cuttingtools.• Equipped with material center setup rack and automatic lubricator to lubricate the slide waysand keeps the slide ways in the optimal lubricated condition.• Industrial full power motor for maximum cutting capacity.• Precision sealed long-life bearing.• Heavy cast iron frame and table for durability usage.

CAM-WOOD SM-545 HS 5-Heads High-Speed Trough Feed /Planer/Moulder(5) Heads (B-R-L-T-T), working cap. 450 mm X 160 mm (17-7" x 6-1/4").Specifications: -- Max/Min working width 17.7" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 20 HP, and top or bottom 20 HP . -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,200 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 260' per minute are a standard feature. -- The full safety enclosure also works as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table permits the table to be positioned extremely close to the cutterheads for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control system. This option consists of motorized adjustment of the head control from the main screen of the machine.This option include: -- 15" HMI (1000 memory setting), -- Servo motor positioning, Simple and easy to operate. -- Width and thickness quickly & auto set-up -- Tools management system -- Lateral chain feeder (quoted with customer material specifications)

CAM-WOOD TX-P3200SAX Sliding Table Panel Saw w/Motorized Raise & Lower.Heavy-duty construction, vibration-free operation. Easy to set up and quickly adjusts. High accuracy, free movement sliding table without wear resistance.Specially designed double rollers carriage made by aluminum profile. Stable, torsion-free cross slides with easy running swinging arm.Features: -- 126" Cutting length w/scoring; 126" x 17" Anodized sliding table that locks in any position for easy loading. -- Motorized Saw blade up or down movement by 1/4 HP electric servo motor; tilting by manual handle wheel. -- Scoring unit for clean, accurate chip-free cutting, ready for edge banding. Specifications: -- 7.5 HP Main saw motor; 45° tilting (30 mm) main saw arbor; 14" Main blade dia.; 3,000/4,000 & 5,600 RPM arbor speed. -- 5.3" Max. material thickness at 90°; 3.1" at 45°. -- 1 HP Scoring saw motor, 5" dia. scoring blade; 8,000 RPM. -- Equipped with: 49" Max. ripping cap.; micro-adjustable rip fence and extendable crosscut fence to 10' with (2) flip stops. -- Articulating overarm protection guard; outboard and rear extension tables. -- Includes: Saw Blade(s), Maintenance Tools, Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD WS-NDA 1300 3-Head Planer Sander[Equipped with Planer, Drum and combi head]Features: -- This machine is especially designed for removing heavy material such as glued-up panels, bent boards, and rough lumber. -- The first station is a knife planer head, followed by a combi head with drum and platen at the second station and a finishing platen head at the third station. -- Head configuration can be made to meet customer’s requirements. -- The spiral planer cutter head is fitted with 14 x 14 MM, four-edge throwaway Tungsten Carbide knife inserts, providing a superior chip removal rate, minimum noise, and an extremely smooth cutting effect. -- Changing knife inserts is convenient without removing the cutter head. The spiral cutter head is precision machined from special aluminum alloy steel, tempered, and precision ground by a CNC machine center. -- Anti-kickback fingers, mounted at the infeed of the machine, this anti-kickback finger gives a safety guard for the operator. -- Insufficient pressure protection: If inadequate working air pressure occurs, the machine brakes automatically for safety guard. -- The irreversible running of the pressure roller runs in a single direction only, giving an additional safety guard for panel kickback. -- Automatic elevation of conveyor table (micro-computer controlled with digital readout): it accurately displays the position of the conveyor table. It automatically moves to the setting thickness for planning and sanding. -- Panel cleaning brush roller: built at the outfeed end of the machine, this cleaning brush roller cleans the powder on the sanded panel. -- Hold-down plate is hard chrome treated for maximum wear resistance.Specifications: -- First head Planer with 40 HP motor -- Second head combi drum & platen with 30 HP motor -- Third head finishing platen with 30 HP motor -- Panel cleaning brush at outfeed with 1/2 HP motor -- Working width: 52" -- Working thickness up to 6 1/4" -- Minimum working length: 21" -- Feed speed 10 FPM to 90FPM inverted driven by 5.5 HP motor -- Table hoist motor 1 HP -- Sanding belt size 52" X 75" -- Floor space requirement: 107" X 103" X 80", weight 12,300 Lbs

CAM-WOOD 102PAAU Raised Panel Door MachineMachines entry door stile and rail door parts as well as cabinet door parts, chair legs and furniture parts, up to 102" in length and 7" in width. One operator to machine profiles for the rail copes, stile and rail sticking and raised panels with rapid changeover, all on one machine with high productivity. Features Include: -- Hydraulic table movement from right to left to achieve powerful cutting and adjust cutting speed variability. Table movements in and out are pneumatically powered following a template with very high accuracy. -- One operator to machine all profiles for stiles and rails on one machine, along with raising all panels both edges top and bottom. -- Capacity for machining a 6" arch/oval on panels and rails, and raising both faces on a raised panel at the same time (arc size varies depending on cutter diameter). -- Raise a curved panel up to 6" radius both on rails and panels. -- Machines door stiles up to 102" in length.Technical Features: -- Hydraulic pump unit for accurate table speed control. -- Simple guide system follows templates for curved or arched profiles and is quickly repositioned for straight machining profiles. -- Cutterhead knives can be stacked on the same spindle to eliminate changing machines to machine door parts. -- Easy stop system for door stiles or rail lengths. Two separate stops work for rail/stile/panel arch cut positions. -- Heavy duty 15 HP motor, allows for high speed cutterhead to eliminate unnecessary sanding. -- Proximity switches control the cutting stroke. Linear guide rails and bearing for a lightweight & smooth slide. -- More than one part may be milled at one time. Pneumatic holddown cylinders hold parts tightly without slide during cutting. -- Easy positioning of parts on a precision ground, cast iron table ensures accurate stile rail and panel machining and alignments.More Specifications: -- Spindle Motor 15 HP @ 7,000 RPM; Hydraulic Motor 1 HP; Feed Speed 0-60 FPM. -- Spindle Diameter 1-1/4"; Spindle Height 7"; -- Depth of Radius Cut 6";; Min. Radius Cut 6" (based on cutter diameter). Dust Hood is 4" dia. Dimension: -- Machine Length 120";; Operating Length 228";; Width 48";; Height 48";, Weight 300 Lbs; Air Supply Required 100 PSINote: Delivery time about 10-12 weeks.

CAM-WOOD WP-16L- V5HX 4 Sided 5 Heads High Speed Planer Designed for furniture, cabinet, flooring, intermittent planning mill work, and other industrial uses. Perfect Planer for S2S and S4S planning, tongue & groove flooring, wall paneling, etc. up to approximately 180 FPM depending on depth of cuts and dimensions of partsSpecifications: -- Width: ¾"; to 16"; -- Height: 3/8"; to 4"; -- Length: Maximum Unlimited, Minimum 70";. -- Maximum Cutting Depth; 8 mm -- Feed Rate 40 to 180 fpmFeatures:Horizontal Top & Bottom with Slip-On Spiral Head or Optional Profile cutter head, Tooling Information. -- Standard supply with Slip-On HAR Series Profile / Spiral Cutter head, Profile Knives combined with Carbide Insert 15 x 15 x 2,5 mm. Max depth of cut 8 mm each side (Standard 7"; O.D. Shaft 46 mm): Vertical with Helical or Optional Profile cutter heads -- Left & Right Side/ Standard HAR Series Vertical profile heads. -- Max depth of cut 8mm, 7"; OD, Spindle arbor diameter: 40 mm, -- Left & Right-side Heads can be profile work with owner provided tooling. Fifth head for moulding or sawing -- 15 HP Top Saw Head, raise/lower power digital by HMIQuality Features: -- Simple touch screen with Digital Positioning Controllers for width, thickness adjustment and variable feed speed. -- Hard Chrome plated table for long life -- Automatic top spindle – cutter head height adjustments entered via HMI touch screen control with PLC. -- Floating bottom infeed rolls for smooth, positive feeding -- Variable feed speeds by VFD. Controlled from touch screen. -- Heavy-duty spindle assemblies for durability & smooth finishes. -- Overhead assembly travels up/down and positions via touch screen control, Assembly is support by (4) hard chromed, polished posts and precision screws. -- Tables, fences, etc. are precision ground, polished and hard chromed to provide long life and smooth feeding. -- Massive, heavy-duty sheet metal frame for vibration absorbing finishes and extra-long bearing life. Compact construction with exclusive see-through top guard. -- Motor Control Center with under voltage and overload protection. UL and CSA labeled electric components.Motor Sizes and Feed Works: -- Top and Bottom Cutter Heads Motors each: 30 HP, 5,000 RPM -- Right & Left Side Cutter Motors each: 25 HP, 5,000 RPM -- Second top head for Top saw head, raised and lowered motorized digitally by HMI, drive motor 15 HP -- Variable Feed speeds from 40 to 180 FPM by VFD (invertor) -- Feed is powered by (2) each 5 HP VFD feed motors, (1) motor drives the top infeed and (1) Motor drives the top outfeed feed rolls. Top powered feed rolls are air cylinder loaded / Floating. (4) idle bottom infeed feed rolls and (4) idle bottom outfeed rolls.Overall dimensions: 167" X 71" X 73".

CAM-WOOD WX-4150 Vertical Grinder-ShredderImpact resistant tooling with excellent wear capability. Specifications & features: -- Vertical-feed Chute, 50 HP - 1,750 RPM drive motor; 41" x 12" infeed chute; (12) rotary cutter sets with cutter head angle to allow aggressive cutting rates and high speed shredding of waste. -- The shaft rest for the cutter head is constructed by round hollow with special angle for cooling during production. -- Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". -- OutPut: -- 1,300 - 1,800 Lbs/Hr, depending on material and moisture content. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD WP-4 S2C-500-12 4-SIDED PLANEROutstanding Performance - Quality Components 4 sided with 6 heads as: top and bottom, left and right, (2) chamfer units -- Floating bottom infeed rolls for smooth, positive feeding -- PLC controls with touch-screen interface for ease of operation -- Variable feed speeds by VFD. Controlled from touch screen -- Drive shaft and universal joint feed roll transmission for each feed roll -- Power elevation of overhead mechanism via touch screen control -- Thickness settings from touch screen control -- With cutterheads and carbide knives for straight knife work -- With spindles for easing top edges -- Tables, fences, etc. are precision ground and hard chromed to provide long life and smooth feeding -- Overhead mechanism travels up/down and is support by (6) hard chromed posts -- Motor Control Center with under voltage and overload protection; includes UL and CSA approved electrical componentsWorking Capacities: -- 19 3/4" wide x 12"; high (500 mm X 305 mm) -- Min. thickness: 3/4"; -- Min. width 2-3/4"; -- Max. depth of cut: 1/4"; all heads -- Max. length: Unlimited -- Min. length: 70"; for feed-thru; butt-feed down to 40". (40"; to 70"; may have minor inaccuracies at edge due the hold-down restrictions) -- Feed speeds from 20 to 66 FPMCutterhead Motors: -- 25 HP Top and Bottom (see optional equipment for larger motors) -- 20 HP Right & Left Side Heads (see optional equipment for larger motors) -- Includes Right & Left Spindles for eased edge at top of board; consists of (2) 1 HP floating spindles to accurately ease top edges. Profile knives in primary side heads ease bottom edges. -- Chamfer motor 1/2 HP Feed Works: -- (2) 5 HP VFD’s -- (1) motor drives top set and (1) motor drives the bottom set of feed rolls -- Boards synchronize top and bottom feed roll speed and torque --Cutterheads and Spindles: -- Top and bottom spindles with 60mm (2.362";) spindle dia. Other diameters on request. -- Includes a set of (2) 4-knife x 20"; long x 5-1/2"; dia. spiral carbide cutterheads. -- Side heads with 40mm spindle dia. Other diameters on request -- Includes a set of (2) 4-knife x 12"; long spiral carbide heads -- Includes (1) set per head: 15 x 15 x 3mm carbide knives with (4) cutting edges -- All spindles with hydro-lock outboard bearings -- Left & Right Side Heads can be used for profile work with owner provided tooling -- Eased Edge Spindles: 30mm"; dia. -- Eased Edge Cutting Circle: 4.9"; -- Powered side pressure device at infeed Dust hoods: -- 6"; dia top and bottom head hoods; 6"; dia. side head hoodsOptional Equipment: -- Optional HP on Top & Bottom Heads, up to 40 HP, -- Optional HP on Right & Left, up to 30 HP, -- Electric Brakes for side spindles, -- Power raise/lower and auto-setting for side spindles, Machine Dimensions and Weight: -- 110" long x 86" wide x 94" high x 15200 Lbs.

CAM-WOOD WX-1504HC Horizontal Grinder w/ConveyorImpact resistant tooling with excellent wear capability. Specifications: -- Horizontal feed with (2) 1 HP infeed roller motors; 20 HP - 1,750 RPM drive motor; -- 15-3/8" x 4" Infeed chute; 8" dia. air discharge.Equipped with: -- (18) Rotary cutter sets with cutter head angle to allow aggressive cutting rates and high-speed shredding of waste; -- (4) Stationary cutter sets; 10" dia. rotor; 680 RPM. -- The shaft rest for the cutter head is constructed by a round hollow with a special angle for cooling during production. Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD WX-1510 Vertical Grinder-ShredderImpact resistant tooling with excellent wear capability. Specifications & features: -- Vertical-feed Chute, 10 HP - 1,750 RPM drive motor; 15" x 11" infeed chute; (6) rotary cutter sets & (2) counter-knives with cutter head angle to allow aggressive cutting rates and high speed shredding of waste. -- The shaft rest for the cutter head is constructed by round hollow with special angle for cooling during production. -- Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". -- OutPut: -- 300 - 900 Lbs/Hr, depending on material and moisture content. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD WX-4751 Vertical Grinder-Shredder Specially designed with push ram, powerful crusher for different materials such as wood, MDF, particle board, plastic, rubber, corn cob, etc. Specifications & features: -- Vertical Hopper 47" x 51"; 50 HP - 1,750 RPM drive motor; (96) rotary cutter sets & (6) stationary cutter sets; cutter-head angle cutting design allows aggressive cutting rates & high speed shredding of waste with maximum durability; 85 RPM rotor speed. -- The shaft rest for the cutterhead is constructed by round hollow with special angle to keep cooling for long hours of usage. -- Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD FSM-460AX Finger Joint ShaperSingle Finger joint Shaper with 8" min. and unlimited max. block length; 4" max. block thickness, maximum timber height to feed into assembly press is 3"; 18" max. block width (horizontal joint only); 18" table working width.Equipped with: -- Shaper spindle powered by 10 HP belt drive motor with 50 mm dia. spindle turning at 5,500 RPM; 160 mm (6.3") max. dia. cutter. -- Trim-saw powered by 5 HP direct drive motor at 2,850 RPM and a 1" dia. saw spindle; swings 180 mm (7") max. blade dia. -- Table cycles 2 to 4 per Min via the hydraulic system with a 2 HP hydraulic power unit. Includes 5" dia. dust outlet.Features: -- Manual Fingerjointer performs end trimming and shaping functions on right and left end of blocks. -- Air-operated clamp holding blocks firmly in place. After the workpiece is clamped, the table feeds past the saw and shaper spindles to perform trimming and finger-joint operations; trim saw cuts blocks exactly 90° ends. -- Shaper spindle is precision-constructed for cutting fingers accurately; swings up to 6" dia. tooling. -- Spindle height adjustment is displayed on the dial readout for easy adjustment. -- Table travels on a precision linear guide for stability; table traverse driven by hydraulic power system smooth and accurate block feeding. -- Variable feed speed permits proper feed for hard or soft wood. -- Cast iron frame and table for durability.

CAM-WOOD MODEL FSG-150X Manual FINGER JOINT GLUE APPLICATOR -- Manual operation of sliding table ; Specification: -- Glue roller type -- Working width 24" maximum -- Working thickness 6" -- Glue roller drive 1/2 HP with reducer -- Standard clus height 4"

CAM-WOOD TG-923 1:1 Profile Knife GrinderEconomical model built for shops with 1 or 3 Moulders or a series of Spindle Shapers.Features: -- Work table and cutterhead moves front to back and left and right. -- Table travels on linear bearing with cross roller rail sets. -- Table travel is designed for extreme accuracy. -- Template holder setup is fast and simple for copy tracer. -- Grinding angle is adjusted on dovetail ways. -- Grinding center DOES NOT change with knife angle adjustments. -- Includes stainless steel water splash guard, coolant tank; with pump and filter, easy and efficient to operate. -- Heavy steel cabinet and stand. -- Cast iron Grinder body. -- Built for high precision and durability.Specifications: -- Grinding Capacity: 12"; dia. x 10"; long. -- Grinding Wheel Size: 7.5" dia. with 60 mm bore. -- Grinding Head Travel: 13". -- Grinding Wheel Speed: infinitely variable from 1,500 to 4,500 RPM. -- Grinding Wheel Motor: 2 HP. -- Coolant Pump Motor: 1/8 HP. -- Net Weight: 1,100 Lbs.
